HCD-AZ2D/AZ5D
3-15. CHASSIS (TOP)
1
screw
(B 2.6
×
8)
4
three screws
(B 2.6
×
8)
3
two screws
(B 2
×
10)
5
chassis (top)
2
lever (CL UP2
)
