Sony HCD-AZ5D - Printed Wiring Board - MS-214 Board; Schematic Diagram - MS-214 Board

3939
HCD-AZ2D/AZ5D
HCD-AZ2D/AZ5D
7-12. PRINTED WIRING BOARD – MS-214 BOARD –
• See page 32 for Circuit Boards Location.
: Uses unleaded solder.
M001
(LOADING)
CN001
1-862-780-
S001
S002
S001
(DISC IN/OUT)
S002
(CHUCKING)
S003
(TRIGGER)
S003
71
6
2
MS-214 BOARD
(11)
11
M
C
DMB10
BOARD
CN202
A
B
C
1 2
(Page 33)
7P
CN001
1TRGSW
2NC
3LDM+
4LDM-
5GND
6CKSW1
7OCSW1
M001
A
4
B
MS-214 BOARD
C
52
DMB10
BOARD
(2/4)
CN202
13
(LOADING)
(DISC IN/OUT)
S001
S002
(CHUCKING)
S003
(TRIGGER)
C
(Page 36)
7-13. SCHEMATIC DIAGRAM – MS-214 BOARD –
