HCD-AZ2D/AZ5D
3-16. LEVER (LOADING-L/R)
lever (loading-R)
Align the horizontal position.
lever (loading-L)
Install the
both levers so that they move symmetrically.
2
two hooks
4
two hooks
BOTTOM VIEW
3
lever (loading-L
5
lever (loading-R)
SPT-T (loading-R) SPR-T (loading-L)
1
1
PRECAUTION DURING LEVER (LOADING R / L) INSTALLATION
