5
HCD-C5
SERVICE POSITION OF THE CD MECHANISM DECK
SERVICE POSITION OF THE MD MECHANISM DECK
CD MECHANISM DECK
(TN-CCD1001Z)
STAND
BD (CD) BOAR
D
UCOM BOARD
CN101
CN204
MD MECHANISM (MDM-7B4M)
MD DIGITAL BOARD
AUDIO BOARD
UCOM BOARD
BD (CD) BOARD
BD (MD) BOARD
CN102
CN102
CN201
CN701
CN103
CN702
CN703
CN601
CN101
CN201
CN204
CN203
PANEL BOARD
