Sony HCD-C5 - Page 71

71
HCD-C5
I/OPin NamePin No. Description
O
I (S)
I
I
I
—
O
SPFD
FGIN
TEST1
TEST2
TEST3
DVSS
EFMO
94
95
96
97
98
99
100
Spindle servo drive PWM signal (+) output to the BH6511FS (IC141)
Input terminal for the test (fixed at “L”)
Ground terminal (digital system)
EFM signal output terminal when recording mode
* I (S) stands for schmitt input, I (A) for analog input, O (3) for 3-state output, and O (A) for analog output in the column I/O.
