Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
91
HCD-C5
R183 1-216-841-11 METAL CHIP 47K 5% 1/16W
R184 1-220-942-11 METAL CHIP 3.3 1% 1/4
R185 1-220-942-11 METAL CHIP 3.3 1% 1/4
R195 1-216-833-11 METAL CHIP 10K 5% 1/16W
R196 1-216-833-11 METAL CHIP 10K 5% 1/16W
R197 1-216-833-11 METAL CHIP 10K 5% 1/16W
R218 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1 KEY) (LIMIT-IN)
S103 1-771-956-21 SWITCH, PUSH (1 KEY) (OUT)
S104 1-771-955-21 SWITCH, PUSH (1 KEY) (PLAY)
S105 1-771-955-21 SWITCH, PUSH (1 KEY) (REC)
< VIBRATOR >
X171 1-781-569-21 OSCILLATOR, CRYSTAL 90MHz
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
1-682-100-11 CONNECTOR BOARD
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
< CONNECTOR >
CN1 1-815-750-11 CONNECTOR
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
1-681-712-11 HP BOARD
∗∗∗∗∗∗∗∗∗
< CAPACITOR >
C337 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C338 1-162-294-31 CERAMIC 0.001uF 10% 50V
C339 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
∗ CN109 1-568-954-11 PIN, CONNECTOR 5P
CN110 1-506-469-11 PIN, CONNECTOR 4P
< JACK >
J103 1-794-702-11 JACK, HEADPHONE (PHONES)
< TRANSISTOR >
Q341 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q391 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
< RESISTOR >
R337 1-249-407-11 CARBON 150 5% 1/4W F
R342 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-249-407-11 CARBON 150 5% 1/4W F
R392 1-216-833-11 METAL CHIP 10K 5% 1/16W
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
1-681-381-11 JACK BOARD
∗∗∗∗∗∗∗∗∗∗∗
< CAPACITOR >
C101 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C122 1-162-964-11 CERAMIC CHIP 1000PF 50V
(AEP,UK,KR)
C151 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
∗ CN107 1-568-934-11 PIN, CONNECTOR 7P
< JACK >
J101 1-793-439-11 JACK (SMALL TYPE) (TAPE OUT)
J102 1-793-439-11 JACK (SMALL TYPE) (TAPE IN)
< RESISTOR >
R101 1-216-845-11 METAL CHIP 100K 5% 1/16W
R151 1-216-845-11 METAL CHIP 100K 5% 1/16W
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
A-4725-732-A MD DIGITAL BOARD, COMPLETE
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
< CAPACITOR >
C200 1-124-584-00 ELECT 100uF 20% 10V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-124-589-11 ELECT 47uF 20% 16V
C203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C204 1-124-261-00 ELECT 10uF 20% 50V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C212 1-124-584-00 ELECT 100uF 20% 10V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C214 1-124-261-00 ELECT 10uF 20% 50V
C215 1-124-261-00 ELECT 10uF 20% 50V
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C219 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C222 1-124-589-11 ELECT 47uF 20% 16V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C701 1-124-584-00 ELECT 100uF 20% 10V
C702 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C703 1-126-245-11 ELECT 330uF 20.00% 6.3V
C704 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C705 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C707 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C719 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C723 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C726 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C730 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C738 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C740 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C742 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C743 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C748 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C749 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C751 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C756 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C791 1-164-156-11 CERAMIC CHIP 0.1uF 25V
BD (MD) CONNECTOR MD DIGITALHP JACK
Ver 1.1 2001.09
To Next Page
