Sony HCD-C5 - Page 97

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
97
HCD-C5
108 1-773-110-11 WIRE (FLAT TYPE) (19 CORE)
154 1-773-138-11 WIRE (FLAT TYPE) (19 CORE)
156 1-757-079-11 WIRE (FLAT TYPE) (17 CORE)
157 1-757-080-11 WIRE (FLAT TYPE) (27 CORE)
408 1-682-101-11 PICK-UP FLEXIBLE BOARD
0 503 1-758-631-11 OPTICAL PICK-UP (OPTIMA-720L1E)
759 1-678-514-11 FLEXIBLE BOARD
0 760 A-4672-541-A OPTICAL PICK-UP (KMS-260B)
HR901 1-500-670-11 HEAD, OVER WRITE
M701 A-4672-898-A MOTOR ASSY, SPINDLE
M702 A-4735-076-A MOTOR ASSY, SLED
M703 A-4735-074-A MOTOR ASSY, LOADING
M901 1-698-997-11 FAN, D.C.
M902 X-4954-023-1 MOTOR ASSY, LOADING
M903 X-4954-020-1 MOTOR ASSY, FEED
M904 X-4954-021-1 MOTOR ASSY, SPINDLE
S1 1-786-214-11 SWITCH (DETECTION)
(Disc IN/8cm Disc detect)
S2 1-786-213-11 SWITCH (DETECTION)
(12cm Disc/12cm Disc Eject End detect)
S3 1-786-213-11 SWITCH (DETECTION)
(Disc Existence, Chucking, Releasing detect)
S4 1-786-214-11 SWITCH (DETECTION) (8cm Disc Eject detect)
S5 1-786-212-11 SWITCH (DETECTION) (LIMIT IN)
S102 1-771-957-11 SWITCH, PUSH (2 KEY) (REFLECT
→
PROTECT)
0 T900 1-437-239-11 TRANSFORMER, POWER (AEP,UK,AUS)
0 T900 1-437-241-11 TRANSFORMER, POWER (HK,KR)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
∗∗∗∗∗∗∗∗∗∗∗∗∗∗
HARDWARE LIST
∗∗∗∗∗∗∗∗∗∗∗∗∗∗
#1 7-685-870-01 SCREW +BVTT 3X5 (S)
#2 7-685-245-19 SCREW +KTP 3X6 TYPE2 NON-SLIT
#3 7-685-852-04 SCREW +BVTT 2X5 (S)
#4 7-685-861-01 SCREW +BVTT 2.6X5 (S)
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-682-565-09 SCREW +B 4X16
#7 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#8 7-684-024-04 N 4, TYPE 2
#9 7-685-104-19 SCREW +P 2X6 TYPE2 NON-SLIT
#10 7-685-504-19 SCREW +BTP 2X6 TYPE2 N-S
#11 7-685-101-11 SCREW +P 2X3 NON-SLIT TYPE2
#12 7-685-103-19 SCREW +P 2X5 TYPE2 NON-SLIT
#13 7-627-553-38 SCREW, PRECISION +P 2X3
#14 7-627-553-28 SCREW, PRECISION +P 2X2.5
#15 7-627-553-17 PRECISION SCREW +P 2X2 TYPE 3
#16 7-627-553-78 SCREW, PRECISION +P 2X10
#17 7-627-553-68 SCREW, PRECISION +P 2X6 TYPE3
#18 7-627-552-77 SCREW, PRECISION +P 1.7X6
#19 7-627-552-88 SCREW, PRECISION +P 1.7X2.2
#20 7-627-551-18 SCREW, PRECISION +P 1.4X2
#21 7-685-850-04 SCREW +BVTT 2X3 (S)
#22 7-685-204-19 SCREW +KTP 2X6 TYPE2 NON-SLIT
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2001.09
