Sony HCD-CBX3 - LOADING MECHANISM SECTION

60
HCD-BX5BT/CBX1/CBX3
not supplied
base unit section
205
205
203
205
203
205
204
201
204
202
not supplied
(MOTOR board)
not supplied
not supplied
7-5. LOADING MECHANISM SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
201 A-1242-967-A LOADING (BK) ASSY
202 3-080-478-01 BELT
203 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
204 4-227-045-41 SPRING (INSULATOR)
205 4-229-005-41 INSULATOR
