Sony HCD-CBX3 - SECTION 8 ELECTRICAL PARTS LIST; 5 V REGULATOR AMP; AMP BOARD

62
HCD-BX5BT/CBX1/CBX3
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
5V REGULATOR
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
When indicating parts by reference number,
please include the board.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
5V REGULATOR BOARD (BX5BT/CBX3)
*******************
< CAPACITOR >
C373 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C380 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< DIODE >
D305 6-501-582-01 DIODE 1N4002-B5
< IC >
IC306 8-759-646-52 IC KIA7805API
< RESISTOR >
R424 1-216-817-11 METAL CHIP 470 5% 1/10W
R437 1-216-797-11 METAL CHIP 10 5% 1/10W
************************************************************
AMP BOARD
*********
< CAPACITOR >
C501 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(CBX3)
C502 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C503 1-126-947-11 ELECT 47uF 20% 35V
C504 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C505 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(CBX3)
C506 1-126-947-11 ELECT 47uF 20% 35V
C509 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(BX5BT/CBX1)
C510 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(BX5BT/CBX1)
C511 1-126-964-11 ELECT 10uF 20% 50V
C512 1-126-964-11 ELECT 10uF 20% 50V
C515 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CBX3)
C518 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CBX3)
C519 1-126-935-11 ELECT 470uF 20% 16V
C521 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CBX3)
C523 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C524 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C525 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C526 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C527 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C528 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C529 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN308 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D501 8-719-080-53 DIODE RK36LF-B3
D502 8-719-080-53 DIODE RK36LF-B3
< EARTH TERMINAL >
EP501 1-537-771-21 TERMINAL BOARD, GROUND (CBX3)
EP502 1-537-771-21 TERMINAL BOARD, GROUND (CBX3)
< IC >
IC601 6-710-800-01 IC STK433-730S-E
< RESISTOR >
R135 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R135 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R136 1-216-837-11 METAL CHIP 22K 5% 1/10W
(CBX3)
R136 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT/CBX1)
R235 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R235 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R236 1-216-837-11 METAL CHIP 22K 5% 1/10W
(CBX3)
R236 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT/CBX1)
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-841-11 METAL CHIP 47K 5% 1/10W
R503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
AMP
