Sony HCD-CBX3 - AMP ANT BT

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
63
HCD-BX5BT/CBX1/CBX3
AMP
R507 1-216-817-11 METAL CHIP 470 5% 1/10W
R508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R509 1-216-841-11 METAL CHIP 47K 5% 1/10W
R510 1-216-817-11 METAL CHIP 470 5% 1/10W
R512 1-216-821-11 METAL CHIP 1K 5% 1/10W
R513 1-216-821-11 METAL CHIP 1K 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R523 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R523 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R524 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R524 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R542 1-260-087-11 CARBON 100 5% 1/2W
R543 1-216-841-11 METAL CHIP 47K 5% 1/10W
R544 1-216-841-11 METAL CHIP 47K 5% 1/10W
R545 1-216-833-11 METAL CHIP 10K 5% 1/10W
R546 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
ANT BOARD (BX5BT)
**********
< CAPACITOR >
C914 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
< CONNECTOR >
CN904 1-818-381-11 CONNECTOR, COAXIAL
************************************************************
A-1236-563-A BT BOARD, COMPLETE (BX5BT)
*******************
< CAPACITOR >
C901 1-126-395-11 ELECT CHIP 22uF 20% 16V
C902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-126-398-11 ELECT CHIP 4.7uF 20% 35V
C905 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-126-204-11 ELECT CHIP 47uF 20% 16V
C908 1-126-204-11 ELECT CHIP 47uF 20% 16V
C912 1-126-204-11 ELECT CHIP 47uF 20% 16V
C921 1-126-193-11 ELECT CHIP 1uF 20% 50V
C922 1-126-193-11 ELECT CHIP 1uF 20% 50V
C923 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C924 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C925 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C926 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C927 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C928 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C929 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C930 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C931 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C932 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C941 1-126-189-11 ELECT CHIP 0.22uF 20% 50V
C942 1-126-189-11 ELECT CHIP 0.22uF 20% 50V
C945 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C946 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C951 1-126-193-11 ELECT CHIP 1uF 20% 50V
C952 1-126-193-11 ELECT CHIP 1uF 20% 50V
C953 1-126-193-11 ELECT CHIP 1uF 20% 50V
C954 1-126-193-11 ELECT CHIP 1uF 20% 50V
C957 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C958 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C965 1-126-189-11 ELECT CHIP 0.22uF 20% 50V
C966 1-126-189-11 ELECT CHIP 0.22uF 20% 50V
C969 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C971 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CN901 1-784-374-51 CONNECTOR, FFC/FPC 15P
CN902 1-573-806-21 PIN, CONNECTOR (1.5mm) (SMD) 6P
CN903 1-573-806-21 PIN, CONNECTOR (1.5mm) (SMD) 6P
< DIODE >
D901 6-500-335-01 DIODE MC2838-T112-1
D902 6-500-335-01 DIODE MC2838-T112-1
< JUMPER RESISTOR/FERRITE BEAD >
FB901 1-216-864-11 SHORT CHIP 0
FB902 1-216-864-11 SHORT CHIP 0
FB903 1-216-864-11 SHORT CHIP 0
FB904 1-216-864-11 SHORT CHIP 0
FB905 1-216-864-11 SHORT CHIP 0
FB906 1-216-864-11 SHORT CHIP 0
FB907 1-400-684-21 INDUCTOR, FERRITE BEAD
FB908 1-216-864-11 SHORT CHIP 0
FB909 1-216-864-11 SHORT CHIP 0
FB910 1-216-864-11 SHORT CHIP 0
FB911 1-216-864-11 SHORT CHIP 0
FB913 1-414-594-11 INDUCTOR, FERRITE BEAD
FB914 1-414-594-11 INDUCTOR, FERRITE BEAD
< IC/BLUETOOTH MODULE >
IC901 6-702-945-01 IC NJM14558V-TE2
IC902 6-702-945-01 IC NJM14558V-TE2
IC903 6-710-962-01 IC XC6213B332MR
IC904 8-753-282-72 CXN1404-5ACL (BLUETOOTH MODULE)
< JUMPER RESISTOR >
JR902 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R900 1-216-809-11 METAL CHIP 100 5% 1/10W
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-809-11 METAL CHIP 100 5% 1/10W
R904 1-216-809-11 METAL CHIP 100 5% 1/10W
R905 1-216-809-11 METAL CHIP 100 5% 1/10W
R906 1-216-809-11 METAL CHIP 100 5% 1/10W
R907 1-216-817-11 METAL CHIP 470 5% 1/10W
R908 1-216-817-11 METAL CHIP 470 5% 1/10W
ANT BT
