Sony HCD-CBX3 - CD FRONT PANEL HEADPHONE

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
66
HCD-BX5BT/CBX1/CBX3
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1236-018-A FRONT PANEL BOARD, COMPLETE (CBX1)
A-1236-335-A FRONT PANEL BOARD, COMPLETE (CBX3)
A-1239-026-A FRONT PANEL BOARD, COMPLETE (BX5BT)
****************************
2-581-391-01 PLATE, LIGHT GUIDE
2-586-988-02 SHEET (LCD), DIFFUSION
< CAPACITOR >
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C835 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C836 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< DIODE >
D802 6-501-539-01 LED SELK5E20C-DTP15 (BLUETOOTH)
(BX5BT)
D802 8-719-061-96 LED SLR-325DCT31 (USB MEMORY) (CBX3)
D803 6-501-139-01 LED SELU2B10A-SLF62 (LCD BACK LIGHT)
(CBX1)
D803 6-501-827-01 LED SELU2610C-S-LF62 (LCD BACK LIGHT)
(CBX3)
D803 6-501-828-01 LED SELK2E10C-D-LF62 (LCD BACK LIGHT)
(BX5BT)
D804 6-501-139-01 LED SELU2B10A-SLF62 (LCD BACK LIGHT)
(CBX1)
D804 6-501-827-01 LED SELU2610C-S-LF62 (LCD BACK LIGHT)
(CBX3)
D804 6-501-828-01 LED SELK2E10C-D-LF62 (LCD BACK LIGHT)
(BX5BT)
D805 6-501-483-01 LED SLR-325VCT31P (STANDBY)
D806 6-501-193-01 DIODE 1SS355WTE-17
< IC >
IC804 6-600-349-31 IC NJL24H400A
< LIQUID CRYSTAL DISPLAY >
LCD801 1-802-377-11 DISPLAY PANEL, LIQUID CRYSTAL
(CBX1/CBX3)
LCD801 1-802-377-21 DISPLAY PANEL, LIQUID CRYSTAL (BX5BT)
< TRANSISTOR >
Q805 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q806 8-729-027-43 TRANSISTOR DTC114EKA-T146
(BX5BT/CBX3)
Q808 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q810 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q811 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R815 1-216-821-11 METAL CHIP 1K 5% 1/10W
R816 1-216-817-11 METAL CHIP 470 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BX5BT/CBX3)
R818 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R819 1-216-809-11 METAL CHIP 100 5% 1/10W
R820 1-216-817-11 METAL CHIP 470 5% 1/10W
R821 1-216-821-11 METAL CHIP 1K 5% 1/10W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R873 1-216-821-11 METAL CHIP 1K 5% 1/10W
R874 1-216-821-11 METAL CHIP 1K 5% 1/10W
R875 1-216-821-11 METAL CHIP 1K 5% 1/10W
R876 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BX5BT)
R877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-821-11 METAL CHIP 1K 5% 1/10W
R879 1-216-821-11 METAL CHIP 1K 5% 1/10W
R880 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BX5BT)
R881 1-216-809-11 METAL CHIP 100 5% 1/10W
R882 1-216-809-11 METAL CHIP 100 5% 1/10W
R890 1-216-864-11 SHORT CHIP 0
R892 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BX5BT/CBX3)
R893 1-216-837-11 METAL CHIP 22K 5% 1/10W
(CBX1/CBX3)
R893 1-216-864-11 SHORT CHIP 0 (BX5BT)
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (I/1)
S802 1-762-875-21 SWITCH, KEYBOARD (BLUETOOTH OPR)
(BX5BT)
S803 1-762-875-21 SWITCH, KEYBOARD (Z)
************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C131 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C231 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C329 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C531 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C581 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-566-822-51 JACK (AUDIO IN)
J500 1-815-629-21 JACK (PHONES)
< RESISTOR >
R132 1-216-841-11 METAL CHIP 47K 5% 1/10W
R133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R232 1-216-841-11 METAL CHIP 47K 5% 1/10W
R233 1-216-821-11 METAL CHIP 1K 5% 1/10W
R531 1-216-817-11 METAL CHIP 470 5% 1/10W
R532 1-216-817-11 METAL CHIP 470 5% 1/10W
R533 1-216-817-11 METAL CHIP 470 5% 1/10W
R534 1-216-813-11 METAL CHIP 220 5% 1/10W
(BX5BT/CBX1)
R534 1-216-817-11 METAL CHIP 470 5% 1/10W
(CBX3)
R535 1-216-813-11 METAL CHIP 220 5% 1/10W
(BX5BT/CBX1)
CD FRONT PANEL HEADPHONE
