Sony HCD-CBX3 - MAIN

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
69
HCD-BX5BT/CBX1/CBX3
JR472 1-216-296-11 SHORT CHIP 0
JR474 1-216-864-11 SHORT CHIP 0
JR475 1-216-864-11 SHORT CHIP 0
JR476 1-216-864-11 SHORT CHIP 0
JR478 1-216-864-11 SHORT CHIP 0 (CBX3)
JR479 1-216-864-11 SHORT CHIP 0 (CBX3)
JR480 1-216-296-11 SHORT CHIP 0 (CBX3)
JR481 1-216-296-11 SHORT CHIP 0 (CBX3)
JR482 1-216-864-11 SHORT CHIP 0
JR483 1-216-864-11 SHORT CHIP 0
JR484 1-216-864-11 SHORT CHIP 0
JR485 1-216-864-11 SHORT CHIP 0
JR486 1-216-296-11 SHORT CHIP 0 (CBX3)
JR489 1-216-296-11 SHORT CHIP 0
JR490 1-216-864-11 SHORT CHIP 0
JR491 1-216-864-11 SHORT CHIP 0
JR492 1-216-296-11 SHORT CHIP 0
JR493 1-216-296-11 SHORT CHIP 0 (CBX3)
JR494 1-216-864-11 SHORT CHIP 0
JR495 1-216-296-11 SHORT CHIP 0
JR497 1-216-296-11 SHORT CHIP 0 (BX5BT)
JR498 1-216-296-11 SHORT CHIP 0 (BX5BT)
JR500 1-216-296-11 SHORT CHIP 0
JR505 1-216-864-11 SHORT CHIP 0
< COIL >
L302 1-410-501-11 INDUCTOR 2.2uH
< TRANSISTOR >
Q103 8-729-920-31 TRANSISTOR DTC343TK
Q203 8-729-920-31 TRANSISTOR DTC343TK
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q303 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q304 8-729-600-22 TRANSISTOR 2SA1235-F
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q309 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q310 8-729-027-43 TRANSISTOR DTC114EKA-T146 (BX5BT)
Q311 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q313 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q314 8-729-027-38 TRANSISTOR DTA144EKA-T146 (CBX3)
Q315 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q318 8-729-027-43 TRANSISTOR DTC114EKA-T146 (CBX3)
Q321 8-729-027-43 TRANSISTOR DTC114EKA-T146 (CBX3)
Q323 8-729-037-13 TRANSISTOR KTA1271Y (BX5BT)
Q324 8-729-027-43 TRANSISTOR DTC114EKA-T146 (BX5BT)
Q325 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (BX5BT)
Q333 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q338 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q340 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q341 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q342 8-729-600-22 TRANSISTOR 2SA1235-F
Q343 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q344 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q390 8-729-028-54 TRANSISTOR KTC3205
Q391 8-729-036-86 TRANSISTOR KTC3203Y-AT (CBX3)
Q392 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q393 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R105 1-216-837-11 METAL CHIP 22K 5% 1/10W
R106 1-216-837-11 METAL CHIP 22K 5% 1/10W
R107 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT)
R108 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT)
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R112 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R114 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT)
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R201 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CBX3)
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT/CBX1)
R202 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R203 1-216-841-11 METAL CHIP 47K 5% 1/10W
R205 1-216-837-11 METAL CHIP 22K 5% 1/10W
R206 1-216-837-11 METAL CHIP 22K 5% 1/10W
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(BX5BT)
R208 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT)
R209 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R211 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R212 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R213 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R214 1-216-841-11 METAL CHIP 47K 5% 1/10W
(BX5BT)
R215 1-216-845-11 METAL CHIP 100K 5% 1/10W
(BX5BT)
R217 1-216-841-11 METAL CHIP 47K 5% 1/10W
R218 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R227 1-216-837-11 METAL CHIP 22K 5% 1/10W
R300 1-216-809-11 METAL CHIP 100 5% 1/10W
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
