Sony HCD-CBX3 - POWER REGULATOR SPEAKER TOP PANEL

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
72
HCD-BX5BT/CBX1/CBX3
< LINE FILTER >
0LF901 1-443-993-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-216-837-11 METAL CHIP 22K 5% 1/10W
R902 1-216-837-11 METAL CHIP 22K 5% 1/10W
0R903 1-219-512-22 METAL 2.2M 5% 1/2W
(BX5BT/CBX1)
R904 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-821-11 METAL CHIP 1K 5% 1/10W
R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
R910 1-216-864-11 SHORT CHIP 0
R911 1-216-864-11 SHORT CHIP 0
< RELAY >
0RY901 1-755-334-11 RELAY, AC POWER
< TRANSFORMER >
0T902 1-443-846-11 TRANSFORMER, POWER (BX5BT/CBX1)
0T902 1-443-912-11 TRANSFORMER, POWER (CBX3)
************************************************************
REGULATOR BOARD
*****************
< CAPACITOR >
C325 1-126-933-11 ELECT 100uF 20% 16V
C335 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< IC >
IC305 6-700-830-01 IC KIA7809API (CBX3)
IC305 8-759-231-56 IC TA7809S (BX5BT/CBX1)
************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C119 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C122 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C123 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(CBX3)
C125 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
(CBX3)
C219 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C222 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C223 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(CBX3)
C225 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
(CBX3)
C304 1-126-960-11 ELECT 1uF 20% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-126-963-11 ELECT 4.7uF 20% 50V
C387 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN313 1-819-131-11 PIN, CONNECTOR 3P
< DIODE >
D313 6-500-335-01 DIODE MC2838-T112-1
< TERMINAL BOARD >
J302 1-780-275-11 TERMINAL BOARD, PUSH (4P)
< COIL >
L101 1-422-009-13 COIL, AIR-CORE
L201 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q307 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q316 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q317 8-729-037-03 TRANSISTOR KTA1266GR-AT
< RESISTOR >
R129 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R130 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R153 1-260-304-51 CARBON 10 5% 1/2W
R229 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R230 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R253 1-260-304-51 CARBON 10 5% 1/2W
R409 1-216-841-11 METAL CHIP 47K 5% 1/10W
R415 1-216-845-11 METAL CHIP 100K 5% 1/10W
R422 1-216-817-11 METAL CHIP 470 5% 1/10W
R428 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R459 1-216-805-11 METAL CHIP 47 5% 1/10W
R460 1-216-805-11 METAL CHIP 47 5% 1/10W
R475 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R478 1-216-833-11 METAL CHIP 10K 5% 1/10W
R481 1-216-805-11 METAL CHIP 47 5% 1/10W
R482 1-216-797-11 METAL CHIP 10 5% 1/10W
R484 1-216-849-11 METAL CHIP 220K 5% 1/10W
R489 1-216-833-11 METAL CHIP 10K 5% 1/10W
(CBX3)
R489 1-216-837-11 METAL CHIP 22K 5% 1/10W
(BX5BT/CBX1)
R498 1-216-833-11 METAL CHIP 10K 5% 1/10W
(CBX3)
R498 1-216-837-11 METAL CHIP 22K 5% 1/10W
(BX5BT/CBX1)
************************************************************
TOP PANEL BOARD
****************
< RESISTOR >
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R855 1-216-833-11 METAL CHIP 10K 5% 1/10W
R856 1-216-837-11 METAL CHIP 22K 5% 1/10W
R857 1-216-841-11 METAL CHIP 47K 5% 1/10W
R858 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CBX1)
POWER REGULATOR SPEAKER TOP PANEL
