Sony HCD-CP1 - Diagrams: Changed Portions (Main Board)

2
EXCEPT
US, CND, AEP, UK
R841
*
0 (US, CND)
2.2k (E, MX, AR)
4.7k (EA, MY, SP, TH, HK, TW, AUS)
1-2. Diagrams
! : Indicates changed portion.
Page Before Change After Change
27
[MAIN BOARD] Location: G-4
23
28
EXCEPT
US, CND, AEP, UK
!
[MAIN BOARD] (2/4) Location: D-5
[MAIN BOARD] (2/4) Location: H-9
[MAIN BOARD] (4/4) Location: E-13
R124, 224
2.2k (E, MX, AR)
22k (EXCEPT E, MX, AR)
*
*
*
#
^
32
%
