– 49 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CD LIGHT CONTROL
1-673-632-11 CD LIGHT BOARD
**************
< CONNECTOR >
CN811 1-785-955-11 CONNECTOR (BOARD TO BOARD)
< DIODE >
D858 8-719-075-50 LED SELS6B14C-TP5
(DISC TRAY ILLUMINATION)
**************************************************************
* A-4419-257-A CONTROL BOARD, COMPLETE
*************************
< CAPACITOR >
C601 1-124-259-11 ELECT 4.7uF 20% 16V
C602 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN603 1-785-957-11 CONNECTOR (BOARD TO BOARD)
CN810 1-778-697-11 HOUSING, CONNECTOR 3P
< DIODE >
D851 8-719-074-42 LED SLR325VR-T31 (STANDBY I/u)
D852 8-719-074-40 LED SLR325DU-T31 (CD)
D853 8-719-074-40 LED SLR325DU-T31 (MD/VIDEO)
D854 8-719-074-40 LED SLR325DU-T31 (TAPE)
D855 8-719-074-40 LED SLR325DU-T31 (TUNER)
D856 8-719-074-42 LED SLR325VR-T31 (DSG)
D857 8-719-074-42 LED SLR325VR-T31 (CD SYNC)
< IC >
IC802 8-742-012-11 HYB IC SBX1976-51
(REMOTE CONTROL RECEIVER)
< TRANSISTOR >
Q852 8-729-900-53 TRANSISTOR DTC114EK
Q853 8-729-900-53 TRANSISTOR DTC114EK
Q854 8-729-900-53 TRANSISTOR DTC114EK
Q855 8-729-900-53 TRANSISTOR DTC114EK
Q856 8-729-900-53 TRANSISTOR DTC114EK
Q857 8-729-900-53 TRANSISTOR DTC114EK
Q858 8-729-900-53 TRANSISTOR DTC114EK
Q859 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R601 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R602 1-216-045-00 METAL CHIP 680 5% 1/10W
R603 1-216-047-00 RES, CHIP 820 5% 1/10W
R604 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R605 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R606 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R607 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R608 1-216-079-00 METAL CHIP 18K 5% 1/10W
R609 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R610 1-216-045-00 METAL CHIP 680 5% 1/10W
R611 1-216-047-00 RES, CHIP 820 5% 1/10W
R612 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R614 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R615 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R616 1-216-079-00 METAL CHIP 18K 5% 1/10W
R617 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R618 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R660 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R661 1-216-033-00 METAL CHIP 220 5% 1/10W
R662 1-216-043-91 RES, CHIP 560 5% 1/10W
R665 1-216-043-91 RES, CHIP 560 5% 1/10W
R666 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R667 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R668 1-216-041-00 METAL CHIP 470 5% 1/10W
R669 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R680 1-216-045-00 METAL CHIP 680 5% 1/10W
R681 1-216-047-00 RES, CHIP 820 5% 1/10W
R683 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R684 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R685 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R686 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R687 1-216-073-00 METAL CHIP 10K 5% 1/10W
R688 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
< VARIABLE RESISTOR >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
S801 1-571-760-11 SWITCH, KEY BOARD (TUNING MODE)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CND : Canadian model
HK : Hong Kong model
MY : Malaysia model
SP : Singapore model
TH : Thai model
