Sony HCD-CP1 - Electrical Parts List: Components and Abbreviations

6
1-4. Electrical Parts List
Page Before Change After Change
Ref. No. Part No. Description Remark
* A-4419-949-A MAIN BOARD, COMPLETE
(EA, MY, SP, TH, HK, TW, AUS)
* A-4426-433-A MAIN BOARD, COMPLETE (E, MX, AR)
R124 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(E, MX, AR)
R124 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EXCEPT E, MX, AR)
R224 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(E, MX, AR)
R224 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EXCEPT E, MX, AR)
R841 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(E, MX, AR)
R841 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
(EA, MY, SP, TH, HK, TW, AUS)
* A-4419-950-A POWER BOARD, COMPLETE
(E, EA, MY, SP, TH, HK, TW, AR)
* A-4426-432-A POWER BOARD, COMPLETE (AUS)
* A-4426-664-A POWER BOARD, COMPLETE (MX)
0 RY901 1-755-321-12 RELAY (AEP, UK)
0 RY901 1-755-333-11 RELAY (US, CND)
0 S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR)
(E, EA, MY, SP, TH, HK, TW, AR)
0 T901 1-433-809-11 TRANSFORMER, POWER
(EXCEPT US, CND, AEP, UK)
*******************************************************
MISCELLANEOUS
**************
112 A-4411-697-A TUNER PACK (EXCEPT US, CND, AEP, UK)
0 116 1-696-169-21 CORD, POWER (EA, HK, MY, SP, TW)
0 116 1-757-166-11 CORD, POWER (AEP, UK)
0 116 1-558-943-31 CORD, POWER (TH)
0 116 1-690-608-11 CORD, POWER (AUS)
0 116 1-775-789-81 CORD, POWER (E, MX)
0 116 1-783-941-21 CORD, POWER (AR)
0 T901 1-433-809-11 TRANSFORMER, POWER
(EXCEPT US, CND, AEP, UK)
********************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-569-008-21 ADAPTOR, CONVERSION 2P (TW)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
Ref. No. Part No. Description Remark
53
* A-4419-949-A MAIN BOARD, COMPLETE
(MY, SP, TH, HK)
R124 1-216-081-00 METAL CHIP 22K 5% 1/10W
R224 1-216-081-00 METAL CHIP 22K 5% 1/10W
R841 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
* A-4419-950-A POWER BOARD, COMPLETE
(MY, SP, TH, HK)
0 RY901 1-755-321-11 RELAY (US, CND, AEP, UK)
0 S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR)
(MY, SP, TH, HK)
0 T901 1-433-809-11 TRANSFORMER, POWER (MY, SP, TH, HK)
*******************************************************
MISCELLANEOUS
**************
112 A-4411-697-A TUNER PACK (MY, SP, TH, HK)
0 116 1-575-651-11 CORD, POWER (UK, HK)
0 116 1-696-169-21 CORD, POWER (AEP, MY, SP, TH)
0 T901 1-433-809-11 TRANSFORMER, POWER (MY, SP, TH, HK)
50
56
• Items marked “*” are not stocked since they are seldom required for
routine service.
Some delay should be anticipated when ordering these items.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
54
55
57
• Abbreviation
AR : Argentine model
AUS : Australian model
CND : Canadian model
EA : Saudi Arabia model
HK : Hong Kong model
MX : Mexican model
MY : Malaysia model
SP : Singapore model
TH : Thai model
TW : Taiwan model
