– 46 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
BD
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-223-587-11 RES, ADJ, CARBON 22K
RV102 1-223-587-11 RES, ADJ, CARBON 22K
RV103 1-223-587-11 RES, ADJ, CARBON 22K
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-657-289-11 CONNECT BOARD (US, CND)
* 1-659-290-11 CONNECT BOARD (EXCEPT US, CND)
**************
< CONNECTOR >
CN507 1-750-189-11 CONNECTOR, BOARD TO BOARD 16P
CN508 1-695-094-11 SOCKET, CONNECTOR 11P
CN509 1-750-179-11 SOCKET, CONNECTOR 5P
************************************************************
* A-4378-477-A DISPLAY BOARD, COMPLETE (E)
* A-4378-886-A DISPLAY BOARD, COMPLETE (D11)
* A-4378-911-A DISPLAY BOARD, COMPLETE (T11:SP, MY, HK)
* A-4390-139-A DISPLAY BOARD, COMPLETE (US, CND)
* A-4392-535-A DISPLAY BOARD, COMPLETE (JE)
************************
1-690-880-51 LEAD (WITH CONNECTOR)
* 4-932-810-11 CUSHION (FL)
* 4-975-363-01 HOLDER (FL TUBE)
< CAPACITOR >
C701 1-126-916-11 ELECT 1000uF 20% 6.3V
C702 1-162-306-11 CERAMIC 0.01uF 30% 16V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C704 1-164-159-11 CERAMIC 0.1uF 50V
C705 1-161-494-00 CERAMIC 0.022uF 25V
C706 1-124-907-11 ELECT 10uF 20% 50V
C707 1-102-953-00 CERAMIC 18PF 5% 50V
C708 1-102-514-11 CERAMIC 22PF 5% 50V
C709 1-124-903-11 ELECT 1uF 20% 50V
C710 1-124-903-11 ELECT 1uF 20% 50V
C714 1-164-159-11 CERAMIC 0.1uF 50V
C715 1-164-159-11 CERAMIC 0.1uF 50V
C750 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
* CN701 1-568-834-11 SOCKET, CONNECTOR 15P
* CN702 1-568-954-11 PIN, CONNECTOR 5P
* CN703 1-568-832-11 SOCKET, CONNECTOR 13P
* CN704 1-568-826-11 SOCKET, CONNECTOR 7P
< CONPOSITION CIRCUIT BLOCK >
CP701 1-233-699-11 COMPOSITION CIRCUIT BLOCK 100K X 6
CP702 1-233-568-11 COMPOSITION CIRCUIT BLOCK 100K X 11
< DIODE >
D701 8-719-200-82 DIODE 11ES2
D702 8-719-987-63 DIODE 1N4148M
D703 8-719-987-63 DIODE 1N4148M
D704 8-719-987-63 DIODE 1N4148M
D705 8-719-052-21 LED SEL58420C-TH8C (^)
D706 8-719-987-63 DIODE 1N4148M
< FLUORESCENT INDICATOR TUBE>
FL701 1-517-441-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 8-759-436-62 IC uPD78044AGF-204-3B9
< COIL >
L701 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q701 8-729-422-73 TRANSISTOR UN4212
Q702 8-729-620-05 TRANSISTOR 2SC2603-EF
