– 47 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
LOADING
MAIN
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-249-417-11 CARBON 1K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W
R707 1-249-417-11 CARBON 1K 5% 1/4W
R708 1-249-417-11 CARBON 1K 5% 1/4W
R709 1-249-437-11 CARBON 47K 5% 1/4W (T11)
R710 1-249-437-11 CARBON 47K 5% 1/4W (D11)
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-417-11 CARBON 1K 5% 1/4W
R713 1-249-417-11 CARBON 1K 5% 1/4W
R714 1-249-409-11 CARBON 220 5% 1/4W
R715 1-249-437-11 CARBON 47K 5% 1/4W
R716 1-249-433-11 CARBON 22K 5% 1/4W
R717 1-249-413-11 CARBON 470 5% 1/4W
R718 1-247-843-11 CARBON 3.3K 5% 1/4W
R719 1-249-425-11 CARBON 4.7K 5% 1/4W
(SP, MY, HK)
R719 1-249-421-11 CARBON 2.2K 5% 1/4W
(E, JE)
R720 1-249-431-11 CARBON 15K 5% 1/4W
(SP, MY, E, HK)
R720 1-247-844-11 CARBON 3.6K 5% 1/4W (JE)
R720 1-249-429-11 CNDRBON 10K 5% 1/4W
(US, CND)
R721 1-247-843-11 CARBON 3.3K 5% 1/4W
R722 1-249-413-11 CARBON 470 5% 1/4W
R723 1-249-415-11 CARBON 680 5% 1/4W
R724 1-249-417-11 CARBON 1K 5% 1/4W
R725 1-249-419-11 CARBON 1.5K 5% 1/4W
R726 1-249-421-11 CARBON 2.2K 5% 1/4W
R727 1-249-409-11 CARBON 220 5% 1/4W
R728 1-249-417-11 CARBON 1K 5% 1/4W
R729 1-249-417-11 CARBON 1K 5% 1/4W
R730 1-249-417-11 CARBON 1K 5% 1/4W
R731 1-249-409-11 CARBON 220 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-409-11 CARBON 220 5% 1/4W
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-417-11 CARBON 1K 5% 1/4W
R736 1-249-417-11 CARBON 1K 5% 1/4W
R737 1-249-409-11 CARBON 220 5% 1/4W
R738 1-249-425-11 CARBON 4.7K 5% 1/4W
R739 1-249-417-11 CARBON 1K 5% 1/4W
R740 1-249-417-11 CARBON 1K 5% 1/4W
R741 1-249-409-11 CARBON 220 5% 1/4W
R742 1-249-437-11 CARBON 47K 5% 1/4W
R743 1-247-807-31 CARBON 100 5% 1/4W
R744 1-249-401-11 CARBON 47 5% 1/4W
R749 1-249-421-11 CARBON 2.2K 5% 1/4W
R750 1-247-891-00 CARBON 330K 5% 1/4W
R751 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S701 1-554-303-21 SWITCH, TACTILE (BAND)
S702 1-554-303-21 SWITCH, TACTILE ()+ TUNING +)
S703 1-554-303-21 SWITCH, TACTILE (6)
S704 1-554-303-21 SWITCH, TACTILE (=0 TUNING -)
S705 1-554-303-21 SWITCH, TACTILE (p)
S706 1-554-303-21 SWITCH, TACTILE (^)
< VIBRATOR >
X701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
* 1-634-461-11 LOADING BOARD
**************
< CONNECTOR >
* CN291 1-564-498-11 PIN, CONNECTOR 5P
< SWITCH >
S291 1-571-924-11 SWITCH, LEAF (LOAD OUT)
S292 1-571-924-11 SWITCH, LEAF (LOAD IN)
************************************************************
* A-4390-992-A MAIN BOARD, COMPLETE (T11: SP, MY, E, HK)
* A-4390-995-A MAIN BOARD, COMPLETE (US,CND)
* A-4390-996-A MAIN BOARD, COMPLETE (D11)
* A-4392-536-A MAIN BOARD, COMPLETE (JE)
**********************
< CAPACITOR >
C102 1-126-965-11 ELECT 22uF 20% 50V
C104 1-124-257-00 ELECT 2.2uF 20% 50V
C108 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C109 1-126-965-11 ELECT 22uF 20% 50V
C110 1-162-306-11 CERAMIC 0.01uF 30% 16V
C111 1-124-120-11 ELECT 220uF 20% 25V
C112 1-162-306-11 CERAMIC 0.01uF 30% 16V
C113 1-124-907-11 ELECT 10uF 20% 50V
C114 1-162-306-11 CERAMIC 0.01uF 30% 16V
C152 1-126-965-11 ELECT 22uF 20% 50V
