– 49 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
Q301 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q302 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q303 8-729-620-05 TRANSISTOR 2SC2603-EF
Q304 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q351 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q352 8-729-620-05 TRANSISTOR 2SC2603-EF
Q354 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R101 1-249-425-11 CARBON 4.7K 5% 1/4W
R102 1-249-426-11 CARBON 5.6K 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R105 1-249-417-11 CARBON 1K 5% 1/4W
R106 1-249-417-11 CARBON 1K 5% 1/4W
R108 1-249-427-11 CARBON 6.8K 5% 1/4W
R109 1-249-433-11 CARBON 22K 5% 1/4W
R110 1-249-433-11 CARBON 22K 5% 1/4W
R112 1-249-417-11 CARBON 1K 5% 1/4W
R113 1-249-433-11 CARBON 22K 5% 1/4W
R114 1-249-425-11 CARBON 4.7K 5% 1/4W
R115 1-247-895-00 CARBON 470K 5% 1/4W
R116 1-247-843-11 CARBON 3.3K 5% 1/4W
(T11)
R117 1-249-417-11 CARBON 1K 5% 1/4W
(T11)
R118 1-249-417-11 CARBON 1K 5% 1/4W
(T11)
R119 1-249-417-11 CARBON 1K 5% 1/4W
R120 1-249-425-11 CARBON 4.7K 5% 1/4W
R121 1-249-421-11 CARBON 2.2K 5% 1/4W
R122 1-249-429-11 CARBON 10K 5% 1/4W
! R123 1-212-857-00 FUSIBLE 10 5% 1/4W F
! R124 1-212-873-11 FUSIBLE 47 5% 1/4W F
R151 1-249-425-11 CARBON 4.7K 5% 1/4W
R152 1-249-426-11 CARBON 5.6K 5% 1/4W
R153 1-249-413-11 CARBON 470 5% 1/4W
R155 1-249-417-11 CARBON 1K 5% 1/4W
R156 1-249-417-11 CARBON 1K 5% 1/4W
R158 1-249-427-11 CARBON 6.8K 5% 1/4W
R166 1-247-843-11 CARBON 3.3K 5% 1/4W
(T11)
R167 1-249-417-11 CARBON 1K 5% 1/4W
(T11)
R168 1-249-417-11 CARBON 1K 5% 1/4W
(T11)
R169 1-249-417-11 CARBON 1K 5% 1/4W
R170 1-249-425-11 CARBON 4.7K 5% 1/4W
R301 1-249-433-11 CARBON 22K 5% 1/4W
R302 1-247-887-00 CARBON 220K 5% 1/4W
R303 1-249-425-11 CARBON 4.7K 5% 1/4W
R304 1-249-413-11 CARBON 470 5% 1/4W
R305 1-249-433-11 CARBON 22K 5% 1/4W
R306 1-249-425-11 CARBON 4.7K 5% 1/4W
R307 1-247-895-00 CARBON 470K 5% 1/4W
R308 1-249-433-11 CARBON 22K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-247-807-31 CARBON 100 5% 1/4W
R311 1-247-887-00 CARBON 220K 5% 1/4W
R312 1-249-433-11 CARBON 22K 5% 1/4W
R313 1-249-433-11 CARBON 22K 5% 1/4W
R314 1-249-417-11 CARBON 1K 5% 1/4W
R315 1-249-413-11 CARBON 470 5% 1/4W
R316 1-249-432-11 CARBON 18K 5% 1/4W
R317 1-249-435-11 CARBON 33K 5% 1/4W
R319 1-247-887-00 CARBON 220K 5% 1/4W
R320 1-249-433-11 CARBON 22K 5% 1/4W
R321 1-249-433-11 CARBON 22K 5% 1/4W
R322 1-249-417-11 CARBON 1K 5% 1/4W
R323 1-249-429-11 CARBON 10K 5% 1/4W
R324 1-249-425-11 CARBON 4.7K 5% 1/4W
R325 1-249-417-11 CARBON 1K 5% 1/4W
R326 1-249-412-11 CARBON 390 5% 1/4W
R327 1-247-895-00 CARBON 470K 5% 1/4W
R328 1-249-427-11 CARBON 6.8K 5% 1/4W
R329 1-249-421-11 CARBON 2.2K 5% 1/4W
R352 1-247-887-00 CARBON 220K 5% 1/4W
R353 1-249-425-11 CARBON 4.7K 5% 1/4W
R354 1-249-413-11 CARBON 470 5% 1/4W
R361 1-247-887-00 CARBON 220K 5% 1/4W
R364 1-249-417-11 CARBON 1K 5% 1/4W
R365 1-249-413-11 CARBON 470 5% 1/4W
R369 1-247-887-00 CARBON 220K 5% 1/4W
R372 1-249-417-11 CARBON 1K 5% 1/4W
R373 1-249-429-11 CARBON 10K 5% 1/4W
R374 1-249-425-11 CARBON 4.7K 5% 1/4W
R375 1-249-417-11 CARBON 1K 5% 1/4W
R376 1-249-412-11 CARBON 390 5% 1/4W
R377 1-247-895-00 CARBON 470K 5% 1/4W
R378 1-249-427-11 CARBON 6.8K 5% 1/4W
R379 1-249-421-11 CARBON 2.2K 5% 1/4W
R401 1-249-433-11 CARBON 22K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W
R403 1-249-425-11 CARBON 4.7K 5% 1/4W
R404 1-249-433-11 CARBON 22K 5% 1/4W
R405 1-247-887-00 CARBON 220K 5% 1/4W
R407 1-249-433-11 CARBON 22K 5% 1/4W
R408 1-249-417-11 CARBON 1K 5% 1/4W
R409 1-249-425-11 CARBON 4.7K 5% 1/4W
R410 1-249-436-11 CARBON 39K 5% 1/4W
R411 1-249-403-11 CARBON 68 5% 1/4W
R451 1-249-433-11 CARBON 22K 5% 1/4W
R452 1-249-417-11 CARBON 1K 5% 1/4W
R453 1-249-425-11 CARBON 4.7K 5% 1/4W
R454 1-249-433-11 CARBON 22K 5% 1/4W
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
