– 50 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R455 1-247-887-00 CARBON 220K 5% 1/4W
R457 1-249-433-11 CARBON 22K 5% 1/4W
R458 1-249-417-11 CARBON 1K 5% 1/4W
R459 1-249-425-11 CARBON 4.7K 5% 1/4W
R460 1-249-436-11 CARBON 39K 5% 1/4W
R461 1-249-403-11 CARBON 68 5% 1/4W
R501 1-247-807-31 CARBON 100 5% 1/4W
R502 1-247-807-31 CARBON 100 5% 1/4W
R503 1-247-807-31 CARBON 100 5% 1/4W
< TUNER UNIT >
TB101 1-233-377-11 ENCAPSULATED COMPONENT (SP, MY, E, HK)
TB101 1-233-376-11 ENCAPSULATED COMPONENT (JE)
TB101 1-693-333-11 TUNER (FCC) (US, CND)
< TERMINAL >
TM101 1-537-238-21 TERMINAL BOARD (ANTENNA)
************************************************************
* 1-657-286-11 PANEL BOARD (US, CND)
* 1-659-288-11 PANEL BOARD (EXCEPT US, CND)
************
< CAPACITOR >
C449 1-162-303-11 CERAMIC 0.0033uF 20% 16V
(US, CND)
C450 1-164-159-11 CERAMIC 0.1uF 50V
C499 1-162-303-11 CERAMIC 0.0033uF 20% 16V
(US, CND)
C711 1-164-159-11 CERAMIC 0.1uF 50V
C712 1-104-396-11 ELECT 10uF 20% 16V
< IC >
IC702 8-749-922-36 IC GP1U50XB
< JACK >
J401 1-764-106-11 JACK (PHONES)
< RESISTOR >
R745 1-249-413-11 CARBON 470 5% 1/4W
R746 1-247-843-11 CARBON 3.3K 5% 1/4W
R747 1-249-415-11 CARBON 680 5% 1/4W
R748 1-249-417-11 CARBON 1K 5% 1/4W
< SWITCH >
S707 1-554-303-21 SWITCH, TACTILE (POWER)
S708 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S709 1-554-303-21 SWITCH, TACTILE (VOL -)
S710 1-554-303-21 SWITCH, TACTILE (VOL +)
************************************************************
* A-4390-993-A POWER BOARD, COMPLETE
(T11:SP, MY, E, JE, HK)
* A-4390-994-A POWER BOARD, COMPLETE (US, CND)
* A-4390-997-A POWER BOARD, COMPLETE (D11)
***********************
1-537-771-21 TERMINAL BOARD, GROUND
* 3-309-144-21 HEAT SINK
* 4-035-555-01 HEAT SINK (EXCEPT US, CND)
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C245 1-164-159-11 CERAMIC 0.1uF 50V (T11)
C246 1-164-159-11 CERAMIC 0.1uF 50V (T11)
C247 1-164-159-11 CERAMIC 0.1uF 50V (T11)
C248 1-162-282-31 CERAMIC 100PF 10% 50V (T11)
C249 1-162-282-31 CERAMIC 100PF 10% 50V (T11)
C298 1-162-282-31 CERAMIC 100PF 10% 50V (T11)
C299 1-162-282-31 CERAMIC 100PF 10% 50V (T11)
C548 1-164-159-11 CERAMIC 0.1uF 50V
C801 1-130-491-00 MYLAR 0.047uF 5% 50V
C802 1-130-491-00 MYLAR 0.047uF 5% 50V
C803 1-126-029-11 ELECT 3300uF 20% 25V
(EXCEPT US, CND)
C803 1-124-523-11 ELECT 4700uF 20% 16V
(US, CND)
C804 1-126-029-11 ELECT 3300uF 20% 25V
(EXCEPT US, CND)
C804 1-124-563-11 ELECT 2200uF 20% 25V
(US, CND)
C805 1-126-024-11 ELECT 220uF 20% 16V
C806 1-126-024-11 ELECT 220uF 20% 16V
C807 1-126-022-11 ELECT 47uF 20% 10V
C808 1-126-023-11 ELECT 100uF 20% 25V
C809 1-126-023-11 ELECT 100uF 20% 25V
C810 1-124-122-11 ELECT 100uF 20% 50V
C811 1-124-122-11 ELECT 100uF 20% 50V
C812 1-126-970-11 ELECT 330uF 20% 50V
C813 1-124-913-11 ELECT 470uF 20% 50V
C814 1-104-664-11 ELECT 47uF 20% 25V
