– 52 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D823 8-719-987-63 DIODE 1N4148M
D824 8-719-200-82 DIODE 11ES2 (EXCEPT US, CND)
D825 8-719-200-82 DIODE 11ES2 (EXCEPT US, CND)
D826 8-719-200-82 DIODE 11ES2
D827 8-719-200-82 DIODE 11ES2
D828 8-719-200-82 DIODE 11ES2
D829 8-719-000-60 DIODE UZL-6M2
D830 8-719-000-60 DIODE UZL-6M2
D831 8-719-000-60 DIODE UZL-6M2
< FUSE >
! F801 1-532-464-51 FUSE (T2.5AL/250V) (EXCEPT US, CND)
! F802 1-532-464-51 FUSE (T2.5AL/250V) (EXCEPT US, CND)
! F801 1-576-105-11 FUSE (2.5A/250V) (US,CND)
! F802 1-576-105-11 FUSE (2.5A/250V) (US,CND)
< FERRITE BEAD >
FB9 1-412-473-21 INDUCTOR 0UH (US, CND)
FB14 1-412-473-21 INDUCTOR 0UH (US, CND)
FB24 1-410-397-21 FERRITE BEAD INDUCTOR (US, CND)
< IC >
IC801 8-759-820-13 IC L78MR06
IC802 8-759-822-09 IC LB1641
< IC LINK/FUSE >
! PS801 1-532-841-21 LINK, IC (1.6A 90VAC 60VPC)
(EXCEPT US, CND)
! PS801 1-532-778-21 FUSE, MICRO (1.6A/125V) (US, CND)
! PS802 1-532-841-21 LINK, IC (1.6A 90VAC 60VPC)
(EXCEPT US, CND)
! PS802 1-532-778-21 FUSE, MICRO (1.6A/125V) (US, CND)
< TRANSISTOR >
Q502 8-729-620-05 TRANSISTOR 2SC2603-EF
Q800 8-729-224-61 TRANSISTOR 2SK246-Y
Q801 8-729-140-96 TRANSISTOR 2SD774-34
Q802 8-729-620-05 TRANSISTOR 2SC2603-EF
Q803 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q804 8-729-140-97 TRANSISTOR 2SB734-34
Q805 8-729-900-80 TRANSISTOR DTC114ES
Q806 8-729-209-15 TRANSISTOR 2SD2012
Q807 8-729-900-80 TRANSISTOR DTC114ES
Q808 8-729-141-83 TRANSISTOR 2SB1094-LK
Q809 8-729-209-15 TRANSISTOR 2SD2012
Q810 8-729-620-05 TRANSISTOR 2SC2603-EF
Q812 8-729-209-15 TRANSISTOR 2SD2012
Q813 8-729-620-05 TRANSISTOR 2SC2603-EF
Q814 8-729-900-80 TRANSISTOR DTC114ES
Q815 8-729-801-93 TRANSISTOR 2SD1387
Q816 8-729-801-84 TRANSISTOR 2SB1013-4
Q817 8-729-900-80 TRANSISTOR DTC114ES
Q818 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R504 1-249-425-11 CARBON 4.7K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-249-393-11 CARBON 10 5% 1/4W
R508 1-249-415-11 CARBON 680 5% 1/4W
R801 1-247-843-11 CARBON 3.3K 5% 1/4W
R802 1-249-415-11 CARBON 680 5% 1/4W
R803 1-249-419-11 CARBON 1.5K 5% 1/4W
R804 1-249-418-11 CARBON 1.2K 5% 1/4W
R805 1-249-425-11 CARBON 4.7K 5% 1/4W
R806 1-249-415-11 CARBON 680 5% 1/4W
R807 1-247-843-11 CARBON 3.3K 5% 1/4W
R808 1-249-430-11 CARBON 12K 5% 1/4W
R809 1-249-429-11 CARBON 10K 5% 1/4W
R810 1-249-409-11 CARBON 220 5% 1/4W
R811 1-249-420-11 CARBON 1.8K 5% 1/4W
R812 1-249-429-11 CARBON 10K 5% 1/4W
R813 1-249-409-11 CARBON 220 5% 1/4W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R816 1-249-425-11 CARBON 4.7K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W
R818 1-249-417-11 CARBON 1K 5% 1/4W
R819 1-249-425-11 CARBON 4.7K 5% 1/4W
R820 1-249-409-11 CARBON 220 5% 1/4W
R821 1-249-425-11 CARBON 4.7K 5% 1/4W
R822 1-249-421-11 CARBON 2.2K 5% 1/4W
R823 1-249-421-11 CARBON 2.2K 5% 1/4W
R824 1-249-409-11 CARBON 220 5% 1/4W
R825 1-247-807-31 CARBON 100 5% 1/4W
R826 1-247-807-31 CARBON 100 5% 1/4W
! R827 1-212-865-00 FUSIBLE 22 5% 1/4W F
R829 1-249-415-11 CARBON 680 5% 1/4W
R830 1-249-425-11 CARBON 4.7K 5% 1/4W
! R832 1-212-873-11 FUSIBLE 47 5% 1/4W F
R861 1-249-389-11 CARBON 4.7 5% 1/4W
(US, CND)
! R891 1-219-155-11 FUSIBLE 0.27 10% 1/4W
(US, CND)
! R892 1-219-155-11 FUSIBLE 0.27 10% 1/4W
(US, CND)
************************************************************
MISCELLANEOUS
***************
7 1-775-731-11 WIRE (FLAT TYPE) (7 CORE)
9 1-775-732-11 WIRE (FLAT TYPE) (13 CORE)
POWER
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
