– 53 –
Ref. No. Part No. Description Remark
12 1-775-733-11 WIRE (FLAT TYPE) (15 CORE)
51 1-775-172-11 WIRE (FLAT TYPE) (19 CORE)
! 58 1-569-008-11 ADAPTOR, CONVERSION 2P (SP, MY)
! 59 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
70 1-775-378-11 CORD (WITH CONNECTOR)
(SYSTEM CONTROL)(T11)
! 155 8-848-367-11 OPTICAL PICK-UP KSS-213B/K-N
156 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNJ1 1-526-794-11 OUTLET, AC (HK, SP, MY)
! CNJ1 1-526-882-00 OUTLET, AC (US, CND, E, JE)
! CNP1 1-558-943-71 CORD, POWER (E, JE)
! CNP1 1-558-945-21 CORD, POWER (POLAR. SPT-1) (US, CND)
! CNP1 1-776-060-11 CORD, POWER (HK, SP, MY)
M101 X-4917-523-4 BASE (OUTSART) ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M903 A-4608-362-A MOTOR (L) ASSY (LOADING)
! T1 1-429-096-11 TRANSFORMER, POWER (EXCEPT US, CND)
!T1 1-429-549-11 TRANSFORMER, POWER (US, CND)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-682-547-09 SCREW (M3X6), S TITE, +BTT
#3 7-685-870-01 SCREW +BVTT 3X5 (S)
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#6 7-624-105-04 STOP RING 2.3, TYPE-E
#7 7-685-234-19 SCREW +KTP 2.6X8 TYPE2 NON-SLIT
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-621-255-15 SCREW +P 2X3
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
4-975-903-01 PLATE(PIN JACK 6P),INDICATION
* 4-977-364-01 COVER (PIN JACK 2P)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
