Sony HCD-DX170 - Printed Wiring Board - IO Section

5252
HCD-DX150/DX170/DX250
HCD-DX150/DX170/DX250
6-21. PRINTED WIRING BOARD – IO SECTION –
• See page 27 for Circuit Boards Location. :Uses unleaded solder.
IC201
IC603
IC602
21
43
S VIDEO
(DVD ONLY)
VIDEO
MONITOR OUT
DVB10
BOARD
CN301
(Page 35)
I
MAIN
BOARD
CN507
(Page 41)
F
1
2
22
23
E
E
COMPONENT VIDEO OUT
P /C
Y
B
B
P /C
R
R
AUDIO IN
L
R
VIDEO/SAT
TUNER
12
A
B
C
D
34567
• Semiconductor
Location
Ref. No. Location
IC201 C-3
IC602 C-5
IC603 C-6
Q603 D-6
Q604 D-6
