8
HCD-DX150/DX170/DX250
SECTION 2
GENERAL
This section is extracted
from instruction manual.
For more information, refer to the pages indicated in parentheses.
Front panel
A "/1 (on/standby) (25, 29, 70)
B Disc tray (29)
C DISC 1-5 (29)
D A (open/close) (29, 70)
E H (play) (29)
F X (pause) (30)
G x (stop) (30, 70)
H ./> (30)
I FUNCTION (29)
J PHONES jack (29)
K VOLUME (29)
L (remote sensor) (12)
M Front panel display (91)
Index to Parts and Controls
Rear panel
A SPEAKER jacks (14)
B VIDEO/SAT AUDIO IN jacks (21, 23)
C COMPONENT VIDEO OUT jacks (19)
D MONITOR OUT (VIDEO / S VIDEO) jacks
(19)
E AM terminal (18)
F FM 75 COAXIAL jack (18)
FRONT R FRONT L SURR R SURR L CENTER WOOFER
SPEAKER
Y
P
B
/C
B
P
R
/C
R
AUDIO IN
DVD ONLY
VIDEO
VIDEOS(DVD ONLY)
R L
VIDEO/SAT
COMPONENT VIDEO OUT
MONITOR OUT
COAXIAL
AM
FM
75
