HCD-DX150/DX170/DX250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C178 1-126-208-21 ELECT CHIP 47uF 20% 4V
C179 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C180 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C181 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C182 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C184 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C187 1-126-208-21 ELECT CHIP 47uF 20% 4V
C188 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C189 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C190 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C191 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C192 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C193 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C195 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C196 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C206 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C209 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-126-204-11 ELECT CHIP 47uF 20% 16V
C218 1-124-779-00 ELECT CHIP 10uF 20% 16V
C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-124-779-00 ELECT CHIP 10uF 20% 16V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C402 1-126-204-11 ELECT CHIP 47uF 20% 16V
C403 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3601 1-117-370-11 CERAMIC CHIP 10uF 10V
C3602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3605 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3608 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3609 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3610 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3611 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4501 1-117-370-11 CERAMIC CHIP 10uF 10V
C4502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN101 1-815-763-11 CONNECTOR, FFC/FPC 24P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-784-370-21 CONNECTOR, FFC/FPC 11P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN301 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
CN302 1-784-366-21 CONNECTOR, FFC/FPC 7P
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN4501 1-784-370-21 CONNECTOR, FFC/FPC 11P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3601 8-719-988-61 DIODE 1SS355TE-17
D3602 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL101 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL104 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL105 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL106 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL107 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL108 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL401 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL4501 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-805-276-01 IC MBM29DL32TF70-CBA1-0501UC
(DMB10: EXCEPT EA, SP, AUS)
IC101 6-805-277-01 IC MBM29DL32TF70-CBA1-0501CE
(DMB10: EA, AUS)
IC101 6-805-278-01 IC MBM29DL32TF70-CBA1-0501GA
(DMB10: SP)
IC101 6-805-718-01 IC S29JL032H70-CBA1-0503CE
(DMB11: EA, AUS)
IC101 6-805-719-01 IC S29JL032H70-CBA1-0503GA (DMB11: SP)
IC101 6-805-784-01 IC S29JL032H70-CBA1-0503UC
(DMB11: EXCEPT EA, SP, AUS)
IC102 6-706-727-01 IC CXD9804R (DMB10)
IC102 6-707-535-01 IC CXD9849R (DMB11)
✩ IC103 (not supplied) IC BR24L64F-WE2
IC104 6-706-390-11 IC HY57V641620HGTP-HDR
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 8-759-667-18 IC PQ018EZ01ZP (DMB10)
IC106 6-708-153-01 IC PQ018EN01ZPH (DMB11)
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC3601 6-707-608-01 IC PCM1803DBR
DMB10
Ver. 1.2
✩ New part of EEP ROM (IC103) on the DMB10 board or DMB11 board cannot be
used. Therefore, if the mounted DMB10 board (A-1088-070-A, etc.) is replaced,
exchange new EEP ROM (IC103) with that used before the replacement.
