Sony HCD-DX20 - Printed Wiring Board - Power Amp Section

3030
HCD-DX20/RG30
6-11. PRINTED WIRING BOARD – POWER AMP SECTION –
• See page 19 for Circuit Boards Location.
Ref. No. Location
D501 B-5
D502 B-4
D541 C-5
D542 A-3
D543 A-3
D551 B-4
IC501 A-5
Q501 B-5
Q503 B-5
Q504 B-5
Q551 B-4
Q581 B-5
• Semiconductor
Location
POWER AMP BOARD
11
(13)
21
(21)
DX20
1-681-448-
D
F
MAIN BOARD
(Page 24)
MAIN BOARD
(Page 24)
RG30
RG30/
DX20:KR
C
TRANS BOARD
(Page 34)
(CHASSIS)
DX20
RG30/
DX20:KR
RG30/DX20:KR
(CHASSIS)
E
E
E
E
E
R513
R519
_
+
1
13
1
13
1
13
2
34567
A
1
B
C
D
