Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
48
HCD-DX20/RG30
BD KEY
DRIVER
R111 1-216-121-11 RES-CHIP 1M 5% 1/10W
R113 1-216-121-11 RES-CHIP 1M 5% 1/10W
R114 1-216-073-00 RES-CHIP 10K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-11 RES-CHIP 1K 5% 1/10W
R118 1-216-025-11 RES-CHIP 100 5% 1/10W
R119 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R123 1-216-073-00 RES-CHIP 10K 5% 1/10W
R124 1-216-097-11 RES-CHIP 100K 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES-CHIP 16K 5% 1/10W
R172 1-216-073-00 RES-CHIP 10K 5% 1/10W
R173 1-216-077-00 RES-CHIP 15K 5% 1/10W
R181 1-216-078-00 RES-CHIP 16K 5% 1/10W
R182 1-216-073-00 RES-CHIP 10K 5% 1/10W
R183 1-216-077-00 RES-CHIP 15K 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
******************************************************
1-675-912-14 DRIVER BOARD
************
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-15 DIODE MTZJ-T-77-3.9A
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
******************************************************
1-681-447-11 KEY BOARD
*********
< DIODE >
D707 8-719-058-04 DIODE SEL5223S-TP15 (REC PAUSE/START)
D708 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D709 8-719-057-97 DIODE SEL5923A-TP15 (KARAOKE PON)
(DX20)
D710 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
< TRANSISTOR >
Q707 8-729-900-80 TRANSISTOR DTC114ES
Q708 8-729-900-80 TRANSISTOR DTC114ES
Q709 8-729-900-80 TRANSISTOR DTC114ES (DX20)
Q710 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-413-11 CARBON 470 5% 1/4W F
R704 1-249-414-11 CARBON 560 5% 1/4W F
R705 1-249-415-11 CARBON 680 5% 1/4W F
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-418-11 CARBON 1.2K 5% 1/4W F
R708 1-249-420-11 CARBON 1.8K 5% 1/4W F
R709 1-249-422-11 CARBON 2.7K 5% 1/4W F
R710 1-247-843-11 CARBON 3.3K 5% 1/4W
R711 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DX20)
R713 1-249-410-11 CARBON 270 5% 1/4W F
R714 1-249-411-11 CARBON 330 5% 1/4W
R715 1-249-413-11 CARBON 470 5% 1/4W F
R716 1-249-414-11 CARBON 560 5% 1/4W F
R717 1-249-415-11 CARBON 680 5% 1/4W F
R718 1-249-417-11 CARBON 1K 5% 1/4W F
R719 1-249-418-11 CARBON 1.2K 5% 1/4W F
R720 1-249-420-11 CARBON 1.8K 5% 1/4W F
R721 1-249-422-11 CARBON 2.7K 5% 1/4W F
R726 1-249-410-11 CARBON 270 5% 1/4W F
R727 1-249-411-11 CARBON 330 5% 1/4W
R728 1-249-413-11 CARBON 470 5% 1/4W F
R729 1-249-414-11 CARBON 560 5% 1/4W F
R730 1-249-415-11 CARBON 680 5% 1/4W F
R731 1-249-417-11 CARBON 1K 5% 1/4W F
R732 1-249-418-11 CARBON 1.2K 5% 1/4W F
R733 1-249-420-11 CARBON 1.8K 5% 1/4W F
R734 1-249-422-11 CARBON 2.7K 5% 1/4W F
R735 1-247-843-11 CARBON 3.3K 5% 1/4W
R736 1-249-425-11 CARBON 4.7K 5% 1/4W F
R737 1-249-427-11 CARBON 6.8K 5% 1/4W F
R745 1-249-411-11 CARBON 330 5% 1/4W
R746 1-249-411-11 CARBON 330 5% 1/4W
R797 1-249-411-11 CARBON 330 5% 1/4W
(DX20)
R798 1-249-411-11 CARBON 330 5% 1/4W
< SWITCH >
S704 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP EX-CHANGE)
S705 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S706 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S707 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S708 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE Z )
S709 1-762-875-21 SWITCH, KEYBOARD (v)
S710 1-762-875-21 SWITCH, KEYBOARD (V)
S711 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
