14
HCD-DZ150K/DZ151KB
3-3. FL BOARD
PRECAUTION DURING THE RETAINER (DS) INSTALLATION
(2) Route the harness as shown below. (3) Route the harness as shown below.
(1) Assemble seven claws securely.
4 shield plate (FR)
8 FL board
3 five screws
(+BVTP 2.6
× 10)
5 two screws
(+BVTP 2.6
× 10)
1 two
rivets
6 wire (flat type)
13core (CN805)
7 wire (flat type)
21core (CN801)
2 retainer (DS)
retainer (DS)
harness
rivet rivet
hole
retainer (DS)
harness
wire (flat type)
groove
groove
retainer (DS)
hole
shield plate (FR)
front panel
FL board
JACK
board
CN806
CN805
wire (flat type) 13core
Route the wire
(flat type) 13core
as shown in the figure.
