HCD-DZ150K/DZ151KB
3-6. DIAT-CON BOARD (EXCEPT RU)
3-7. IO-S-OUT BOARD
4
screw
(+BVTP
3
×
8
)
7
DIAT-CON board
q;
two screws
(+BVTP
3
×
8
)
8
two screws
(+BVTP
3
×
8
)
qa
case (diat )
3
Remove the harness.
5
claw
6
claw
1
wire (flat type)
11core
9
lid (diat-p)
2
connector
2p (CN903)
7
three
screws
(+BVTP
3
×
8
)
8
screw
(+BV
3
×
6
)
9
IO-S-OUT board
4
wire (flat type)
17core (CN309)
5
wire (flat type)
5core (CN307)
6
connector
5p (CN302)
3
wire (flat type)
11core (CN304)
1
two screws
(+BV
3
×
6
)
2
bracket
(DIAT DS)
Ver. 1.1
