60
HCD-DZ20
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
•Abbreviation
AR : Argentine model
E3 : 220 – 240 V AC area in E model
E12 : 220 – 240 V AC area in E model
E32 : 110 – 240 V AC area in E model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FL
A-1220-174-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-126-947-11 ELECT 47uF 20% 35V
C803 1-126-933-11 ELECT 100uF 20% 16V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C809 1-126-157-11 ELECT 10uF 20% 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C814 1-126-157-11 ELECT 10uF 20% 16V
C829 1-124-259-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN801 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN805 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D801 6-501-193-01 DIODE 1SS355WTE-17
D802 6-501-193-01 DIODE 1SS355WTE-17
D803 6-501-169-01 DIODE UDZW-TE17-6.2B
D804 6-501-193-01 DIODE 1SS355WTE-17
D805 6-501-193-01 DIODE 1SS355WTE-17
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-643-83 IC uPD16315GB-3BS
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND001 1-451-590-11 VACUUM FLUORESCENT DISPLAYS
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R800 1-216-864-11 SHORT CHIP 0
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-1220-177-A IO BOARD, COMPLETE (AEP, UK)
A-1220-207-A IO BOARD, COMPLETE (RU)
A-1251-054-A IO BOARD, COMPLETE (EXCEPT AEP, UK, RU)
******************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK)
C207 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP, UK)
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK)
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-925-91 ELECT 470uF 20% 10V
C211 1-126-933-11 ELECT 100uF 20% 16V
(AEP, UK)
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK)
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
(EXCEPT AEP, UK)
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-916-11 ELECT 1000uF 20% 6.3V
(AEP, UK)
IO
MX : Mexican model
RU : Russian model
SP : Singapore model
TH : Thai model
Ver. 1.2
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
