HCD-DZ20
SECTION 2
GENERAL
Front panel
A "/1 (on/standby) (18)
B A (open/close) (18)
C Disc operation (18)
D FUNCTION (18)
E Front panel display (78)
F (remote sensor) (8)
G VOLUME control (18)
H Disc tray (18)
R
AEP, UK MODEL
EXCEPT AEP, UK MODEL
ear panel
A SPEAKER jacks (9)
B EURO AV T OUTPUT (TO TV) jack (9)
C AM terminal (9)
D COAXIAL FM 75Ω jack (9)
SPEAKER
ANTENNA
FRONT R FRONT L SUR R SUR L CENTER WOOFER
EURO AV
OUTPUT(TO TV)
COAXIAL
AM
FM75
A SPEAKER jacks (9)
B TV/VIDEO (AUDIO IN R/L) jacks (21)
C MONITOR OUT (S VIDEO/VIDEO) jacks
(18)
D AM terminal (9)
E COAXIAL FM 75Ω jack (9)
F COMPONENT VIDEO OUT jacks (18)
SPEAKER
ANTENNA
COMPONENT VIDEO OUT
FRONT R FRONT L SUR R SUR L CENTER WOOFER
TV/VIDEO
MONITOR OUT
COAXIAL
AM
FM75
RLAUDIO IN
(DVD ONLY)
YPB/CB PR/CR
VIDEO
(DVD ONLY)
S VIDEO
This section is extracted
from instruction manual.
