66
HCD-DZ20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
0 D926 6-501-174-01 DIODE UDZW-TE17-10B
D931 6-501-849-01 DIODE FMX-22SL
D932 6-501-167-01 DIODE UDZW-TE17-5.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 6-501-181-01 DIODE UDZW-TE17-20B
< FERRITE BEAD >
FB1105 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1111 1-469-670-21 FERRITE, EMI (SMD) (2012)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< FUSIBLE RESISTOR >
0 FR901 1-242-949-11 FUSIBLE 0.1 10% 1W
0 FR902 1-242-949-11 FUSIBLE 0.1 10% 1W
(MX)
< IC >
IC501 6-807-417-01 IC M30622MEP-B20FPU0
IC502 6-702-302-01 IC TK11133CSCL-G
IC511 6-708-922-01 IC PST3635NR
IC515 6-703-550-01 IC TA7809LS
IC516 6-703-547-01 IC TA7805LS
0 IC901 6-707-741-01 IC STR-F6138-LF1352 (MX)
0 IC901 6-707-742-01 IC STR-F6168-LF1352 (EXCEPT MX)
0 IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-707-746-01 IC SI-3120KM-TL
IC942 6-707-745-10 IC SI-3050KM-TL
IC943 6-705-308-01 IC SI-3010KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
IC1101 6-707-535-01 IC CXD9849R
IC1102 6-807-171-01 IC S29AL032D70TF-OBA2-0701UC
(E32, MX, AR)
IC1102 6-807-172-01 IC S29AL032D70TF-OBA2-0701CE
(AEP, UK, E3, E12, RU)
IC1102 6-807-432-01 IC S29AL032D70TF-OBA2-0701GA (SP)
IC1102 6-807-748-01 IC MX29LV320CBTC70-OBA2-0701GA (TH)
IC1103 not supplied IC BR24L64F-WE2
IC1104 6-709-370-01 IC A2V64S40CTP-G75
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1109 6-707-485-01 IC NJM2885DL1-18 (TE2)
IC1201 6-704-524-01 IC FAN8036L
IC2200 6-710-554-01 IC PCM1808PWR
IC3003 8-759-680-48 IC TC7WH157FK (TE85R)
IC3010 6-707-939-01 IC CXD9843AR
IC3020 6-707-939-01 IC CXD9843AR
IC3030 6-707-939-01 IC CXD9843AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC3100 6-704-802-01 IC CXD9774M
IC3150 6-704-802-01 IC CXD9774M
IC3200 6-704-802-01 IC CXD9774M
IC3250 6-704-802-01 IC CXD9774M
IC3300 6-704-802-01 IC CXD9774M
IC3400 6-704-802-01 IC CXD9774M
< JUMPER RESISTOR >
JC501 1-216-864-11 SHORT CHIP 0
JC511 1-216-864-11 SHORT CHIP 0 (SP, TH)
JC512 1-216-864-11 SHORT CHIP 0 (E12)
JC513 1-216-864-11 SHORT CHIP 0 (E3)
JC515 1-216-864-11 SHORT CHIP 0 (UK)
JC519 1-216-864-11 SHORT CHIP 0 (E32)
JC520 1-216-864-11 SHORT CHIP 0 (AR)
JC522 1-216-864-11 SHORT CHIP 0 (RU)
JC523 1-216-864-11 SHORT CHIP 0 (AEP)
JC524 1-216-864-11 SHORT CHIP 0 (MX)
< COIL >
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
L2200 1-414-754-11 INDUCTOR 10uH
L3001 1-457-078-11 AIR-CORE COIL
L3002 1-457-078-11 AIR-CORE COIL
L3003 1-457-078-11 AIR-CORE COIL
L3004 1-457-078-11 AIR-CORE COIL
L3005 1-457-078-11 AIR-CORE COIL
L3006 1-457-078-11 AIR-CORE COIL
L3011 1-457-077-11 AIR-CORE COIL
L3012 1-457-077-11 AIR-CORE COIL
L3013 1-457-077-11 AIR-CORE COIL
L3014 1-457-077-11 AIR-CORE COIL
L3015 1-457-077-11 AIR-CORE COIL
L3016 1-457-077-11 AIR-CORE COIL
L3051 1-414-754-11 INDUCTOR 10uH
L3052 1-414-754-11 INDUCTOR 10uH
L3053 1-414-754-11 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3111 1-456-680-11 INDUCTOR 10uH
L3112 1-456-680-11 INDUCTOR 10uH
L3151 1-456-680-11 INDUCTOR 10uH
L3152 1-456-680-11 INDUCTOR 10uH
L3201 1-456-680-11 INDUCTOR 10uH
L3202 1-456-680-11 INDUCTOR 10uH
L3251 1-456-680-11 INDUCTOR 10uH
L3252 1-456-680-11 INDUCTOR 10uH
L3301 1-456-680-11 INDUCTOR 10uH
L3302 1-456-680-11 INDUCTOR 10uH
L3401 1-456-680-11 INDUCTOR 10uH
L3402 1-456-680-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER
0 LF902 1-457-054-21 COIL, LINE FILTER (EXCEPT MX)
< PHOTO COUPLER >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
Ver. 1.2
