70
HCD-DZ20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MS-203
MAIN
R3176 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3177 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3201 1-216-809-11 METAL CHIP 100 5% 1/10W
R3202 1-216-809-11 METAL CHIP 100 5% 1/10W
R3204 1-216-864-11 SHORT CHIP 0
R3207 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3209 1-216-864-11 SHORT CHIP 0
R3211 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3212 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3221 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3222 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3225 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3226 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3227 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3251 1-216-809-11 METAL CHIP 100 5% 1/10W
R3252 1-216-809-11 METAL CHIP 100 5% 1/10W
R3254 1-216-864-11 SHORT CHIP 0
R3257 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3259 1-216-864-11 SHORT CHIP 0
R3261 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3262 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3272 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3273 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3274 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3275 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3276 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3277 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3301 1-216-809-11 METAL CHIP 100 5% 1/10W
R3302 1-216-809-11 METAL CHIP 100 5% 1/10W
R3304 1-216-864-11 SHORT CHIP 0
R3307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3309 1-216-864-11 SHORT CHIP 0
R3311 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3312 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3321 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3323 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3324 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3327 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3401 1-216-809-11 METAL CHIP 100 5% 1/10W
R3402 1-216-809-11 METAL CHIP 100 5% 1/10W
R3404 1-216-864-11 SHORT CHIP 0
R3407 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3409 1-216-864-11 SHORT CHIP 0
R3411 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3412 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R3421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3425 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
< NETWORK RESISTOR >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1113 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1114 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1115 1-234-372-11 RES, NETWORK 100 (1005X4)
< TRANSFORMER >
0 T901 1-443-649-11 TRANSFORMER, CONVERTER (MX)
0 T901 1-443-874-11 TRANSFORMER, CONVERTER (EXCEPT MX)
0 T902 1-443-650-11 TRANSFORMER, CONVERTER
< TERMINAL >
TB3001 1-780-202-11 TERMINAL BOARD (SP) (4P)
(SPEAKER/SUR R, SUR L, FRONT L, FRONT R)
TB3002 1-780-203-11 TERMINAL BOARD (SP) (2P)
(SPEAKER/WOOFER, CENTER)
< THERMISTOR >
0 TH901 1-805-841-21 THERMISTOR, NTC 3.0 (MX, E32)
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0 (EXCEPT MX, E32)
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
< VIBRATOR >
X502 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1102 1-813-539-11 QUARTZ CRYSTAL UNIT (27MHz)
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT (49.1MHz)
*************************************************************
MS-203 BOARD
*************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK / TRAY DETECT)
*************************************************************
P-SW BOARD
***********
< CAPACITOR >
C851 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
