Pin No. Pin Name I/O Description
249 RFGND — Ground terminal
250 NC O EQ offset loop capacitance (not used (Open))
251 NC O EQ offset loop capacitance (not used (Open))
252 OSP O RF offset cancellation capacitor connecting
253 OSN I RF offset cancellation capacitor connecting
254 RFGC O RF offset loop capacitor connecting for DVD-ROM
255 IREF I Current reference input
256 AVDD3 — Power Supply (+3.3V)
