Sony HCD-DZ30 - General Overview and Panel Identification

HCD-DZ30
8
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Front panel
" / (on/standby) (18)
# " (open/close) (18)
$ Disc operation (18)
% FUNCTION (18)
& Front panel display (78)
' (remote sensor) (8)
( VOLUME control (18)
) Disc tray (18)
R
AEP, UK MODEL
EXCEPT AEP, UK MODEL
ear panel
" SPEAKER jacks (9)
# EURO AV 5 OUTPUT (TO TV) jack (9)
$ AM terminal (9)
% COAXIAL FM 75Ω jack (9)
SPEAKER
ANTENNA
FRONT R FRONT L SUR R SUR L CENTER WOOFER
EURO AV
OUTPUT(TO TV)
COAXIAL
AM
FM75
" SPEAKER jacks (9)
# TV/VIDEO (AUDIO IN R/L) jacks (21)
$ MONITOR OUT (S VIDEO/VIDEO) jacks
(18)
% AM terminal (9)
& COAXIAL FM 75Ω jack (9)
' COMPONENT VIDEO OUT jacks (18)
SPEAKER
ANTENNA
COMPONENT VIDEO OUT
FRONT R FRONT L SUR R SUR L CENTER WOOFER
TV/VIDEO
MONITOR OUT
COAXIAL
AM
FM75
RLAUDIO IN
(DVD ONLY)
YPB/CB PR/CR
VIDEO
(DVD ONLY)
S VIDEO
