Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ30
60
C228 1-126-916-11 ELECT 1000uF 20% 6.3V
(AEP,UK)
C228 1-126-933-11 ELECT 100uF 20% 16V
(EXCEPT AEP,UK)
C294 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK)
C500 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP,UK)
C501 1-104-662-11 ELECT 22uF 20% 25V
(AEP,UK)
C550 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP,UK)
C551 1-104-662-11 ELECT 22uF 20% 25V
(AEP,UK)
C600 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT AEP,UK)
C601 1-104-662-11 ELECT 22uF 20% 25V
(EXCEPT AEP,UK)
C602 1-104-662-11 ELECT 22uF 20% 25V
C605 1-126-960-11 ELECT 1uF 20% 50V
C621 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C622 1-104-662-11 ELECT 22uF 20% 25V
C624 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C625 1-126-933-11 ELECT 100uF 20% 16V
C630 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT AEP,UK)
C650 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT AEP,UK)
C651 1-104-662-11 ELECT 22uF 20% 25V
(EXCEPT AEP,UK)
C652 1-104-662-11 ELECT 22uF 20% 25V
C655 1-126-960-11 ELECT 1uF 20% 50V
C700 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP,UK,RU)
C701 1-104-662-11 ELECT 22uF 20% 25V
C720 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C721 1-126-933-11 ELECT 100uF 20% 16V
C750 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP,UK,RU)
C751 1-104-662-11 ELECT 22uF 20% 25V
< CONNECTOR >
CN101 1-568-830-11 CONNECTOR, FFC 11P (AEP,UK)
CN102 1-568-828-11 CONNECTOR, FFC 9P (EXCEPT AEP,UK)
CN201 1-779-281-11 CONNECTOR, FFC (LIF(NON-ZIF)) 13P
CN601 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P (AEP,UK)
CN602 1-779-283-11 CONNECTOR, FFC (LIF(NON-ZIF)) 15P
(EXCEPT AEP,UK)
< DIODE >
D200 6-501-193-01 DIODE 1SS355WTE-17 (AEP,UK)
D201 6-501-193-01 DIODE 1SS355WTE-17 (AEP,UK)
D601 6-501-193-01 DIODE 1SS355WTE-17 (EXCEPT AEP,UK)
D602 6-501-193-01 DIODE 1SS355WTE-17 (EXCEPT AEP,UK)
< IC >
IC201 6-710-470-01 IC MM1758AFBE
IC602 8-759-385-76
IC MC14052 BDR2
IC603 8-759-100-96 IC uPC4558G2
< JACK >
J200 1-778-940-11 JACK, PIN 2P (TV/VCR) (EXCEPT AEP,UK)
< TERMINAL BOARD >
J201 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT S VIDEO/VIDEO)
(EXCEPT AEP,UK)
< JACK >
J202 1-817-601-11 JACK, PIN 3P (COMPONENT VIDEO OUT
Y,PB/CB,PR/CR) (EXCEPT AEP,UK)
< CONNECTOR >
J203 1-816-044-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV OUTPUT) (AEP,UK)
< COIL >
L201 1-469-525-11 INDUCTOR 10uH
L701 1-469-525-11 INDUCTOR 10uH
< TRANSISTOR >
Q203 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (AEP,UK)
Q204 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (AEP,UK)
Q205 8-729-027-23 TRANSISTOR DTA114EKA-T146 (AEP,UK)
Q206 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (AEP,UK)
Q207 8-729-027-23 TRANSISTOR DTA114EKA-T146 (AEP,UK)
Q208 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF (AEP,UK)
Q210 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (AEP,UK)
Q603 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R200 1-216-864-11 SHORT CHIP 0 (AEP,UK)
R201 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP,UK)
R202 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP,UK)
R206 1-216-864-11 SHORT CHIP 0 (AEP,UK)
R207 1-216-864-11 SHORT CHIP 0 (AEP,UK)
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP,UK)
R212 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP,UK)
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT AEP,UK)
R229 1-247-804-11 CARBON 75 5% 1/4W F
(EXCEPT AEP,UK)
R230 1-247-804-11 CARBON 75 5% 1/4W F
R231 1-247-804-11 CARBON 75 5% 1/4W F
R232 1-247-804-11 CARBON 75 5% 1/4W F
R233 1-247-804-11 CARBON 75 5% 1/4W F
R240 1-216-815-11 METAL CHIP 330 5% 1/10W
(AEP,UK)
R241 1-247-804-11 CARBON 75 5% 1/4W F
(EXCEPT AEP,UK)
R242 1-216-815-11 METAL CHIP 330 5% 1/10W
(AEP,UK)
R243 1-216-815-11 METAL CHIP 330 5% 1/10W
(AEP,UK)
R244 1-216-815-11 METAL CHIP 330 5% 1/10W
(AEP,UK)
R246 1-216-837-11 METAL CHIP 22K 5% 1/10W
(AEP,UK)
R247 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(AEP,UK)
IO
Ver. 1.1
