– 52 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
LD201 8-719-989-30 DIODE EL204HD (WIDE)
LD202 8-719-989-30 DIODE EL204HD (NEAR F)
LD203 8-719-989-30 DIODE EL204HD (DBFB)
LD204 8-719-989-30 DIODE EL204HD (CD SYNC)
LD205 8-719-989-30 DIODE EL204HD (REC)
< CONNECTOR >
M201 1-784-348-11 CONNECTOR 12P
M202 1-784-347-11 CONNECTOR 10P
M203 1-784-349-11 CONNECTOR 25P
< LAMP >
PL201 1-517-743-11 LAMP
< TRANSISTOR >
Q201 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q204 8-729-900-63 TRANSISTOR DTA124ES
Q205 8-729-900-63 TRANSISTOR DTA124ES
Q206 8-729-900-63 TRANSISTOR DTA124ES
Q207 8-729-900-63 TRANSISTOR DTA124ES
Q208 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R200 1-249-429-11 CARBON 10K 5% 1/4W
R201 1-249-435-11 CARBON 33K 5% 1/4W
R202 1-249-424-11 CARBON 3.9K 5% 1/4W F
R203 1-249-429-11 CARBON 10K 5% 1/4W
R204 1-249-437-11 CARBON 47K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-249-437-11 CARBON 47K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-249-429-11 CARBON 10K 5% 1/4W
R222 1-249-429-11 CARBON 10K 5% 1/4W
R223 1-249-429-11 CARBON 10K 5% 1/4W
R225 1-249-429-11 CARBON 10K 5% 1/4W
R226 1-249-429-11 CARBON 10K 5% 1/4W
R227 1-249-429-11 CARBON 10K 5% 1/4W
R229 1-249-429-11 CARBON 10K 5% 1/4W
R230 1-249-429-11 CARBON 10K 5% 1/4W
R239 1-249-425-11 CARBON 4.7K 5% 1/4W F
R240 1-249-425-11 CARBON 4.7K 5% 1/4W F
R246 1-249-429-11 CARBON 10K 5% 1/4W
R247 1-249-429-11 CARBON 10K 5% 1/4W
R248 1-249-429-11 CARBON 10K 5% 1/4W
R250 1-247-807-31 CARBON 100 5% 1/4W
R253 1-249-425-11 CARBON 4.7K 5% 1/4W F
(US,CND,AEP,UK,EE,CIS)
R254 1-249-420-11 CARBON 1.8K 5% 1/4W F
(US,CND)
R254 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK,EE,CIS)
R255 1-249-413-11 CARBON 470 5% 1/4W F
R256 1-249-412-11 CARBON 390 5% 1/4W F
R257 1-249-412-11 CARBON 390 5% 1/4W F
R258 1-249-414-11 CARBON 560 5% 1/4W F
R259 1-249-415-11 CARBON 680 5% 1/4W F
R260 1-247-828-11 CARBON 750 5% 1/4W
R261 1-249-416-11 CARBON 820 5% 1/4W F
R262 1-249-418-11 CARBON 1.2K 5% 1/4W F
(US,CND)
R263 1-249-419-11 CARBON 1.5K 5% 1/4W F
R264 1-247-838-00 CARBON 2K 5% 1/4W
R270 1-249-393-11 CARBON 10 5% 1/4W F
R278 1-249-413-11 CARBON 470 5% 1/4W F
R279 1-249-413-11 CARBON 470 5% 1/4W F
R280 1-249-413-11 CARBON 470 5% 1/4W F
R281 1-249-413-11 CARBON 470 5% 1/4W F
R282 1-249-413-11 CARBON 470 5% 1/4W F
R290 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S200 1-571-760-11 SWITCH, KEY BOARD (POWER)
S201 1-571-760-11 SWITCH, KEY BOARD (VOLUME +)
S202 1-571-760-11 SWITCH, KEY BOARD (VOLUME –)
S203 1-571-760-11 SWITCH, KEY BOARD (TUNING +/) +)
S204 1-571-760-11 SWITCH, KEY BOARD (TUNING = 0/–)
S205 1-571-760-11 SWITCH, KEY BOARD (BAND P/FM)
S206 1-571-760-11 SWITCH, KEY BOARD (BAND AM/p)
S207 1-571-760-11 SWITCH, KEY BOARD (PLAY ª TC)
S208 1-571-760-11 SWITCH, KEY BOARD (PLAY CD/TC ·)
S209 1-571-760-11 SWITCH, KEY BOARD (FUNCTION)
S210 1-571-760-11 SWITCH, KEY BOARD (SOUND MODE)
< VIBRATOR >
X201 1-767-791-11 VIBRATOR, CRYSTAL (8MHz)
< LIQUID CRYSTAL DISPLAY >
Z201 1-803-020-11 DISPLAY PANEL, LIQUID CRYSTAL
**************************************************************
* A-4407-242-A FUN/SURROUND BOARD, COMPLETE
*****************************
* 4-997-378-01 PC BOARD BRACKET
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C307 1-102-074-00 CERAMIC 0.001uF 10% 50V
C308 1-102-074-00 CERAMIC 0.001uF 10% 50V
C309 1-124-907-11 ELECT 10uF 20% 50V
C310 1-126-963-11 ELECT 4.7uF 20% 50V
C311 1-161-772-11 CERAMIC 0.1uF 10% 25V
C312 1-161-772-11 CERAMIC 0.1uF 10% 25V
C313 1-126-963-11 ELECT 4.7uF 20% 50V
C314 1-126-963-11 ELECT 4.7uF 20% 50V
C315 1-124-907-11 ELECT 10uF 20% 50V
C316 1-124-907-11 ELECT 10uF 20% 50V
C317 1-124-443-00 ELECT 100uF 20% 10V
C318 1-124-443-00 ELECT 100uF 20% 10V
C319 1-102-114-00 CERAMIC 470PF 10% 50V
C320 1-102-114-00 CERAMIC 470PF 10% 50V
C351 1-137-378-11 FILM 0.22uF 5% 50V
C352 1-137-378-11 FILM 0.22uF 5% 50V
DISPLAY FUN/SURROUND
