Sony HCD-ED1A - Page 37

– 53 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C353 1-137-378-11 FILM 0.22uF 5% 50V
C354 1-137-378-11 FILM 0.22uF 5% 50V
C355 1-137-371-11 FILM 0.015uF 5% 50V
C356 1-137-365-11 FILM 0.0015uF 5% 50V
C357 1-130-489-00 MYLAR 0.033uF 5% 50V
C358 1-137-367-11 FILM 0.0033uF 5% 50V
C359 1-130-481-00 MYLAR 0.0068uF 5% 50V
C360 1-137-367-11 FILM 0.0033uF 5% 50V
C361 1-130-481-00 MYLAR 0.0068uF 5% 50V
C362 1-137-365-11 FILM 0.0015uF 5% 50V
C363 1-137-365-11 FILM 0.0015uF 5% 50V
C365 1-124-907-11 ELECT 10uF 20% 50V
C366 1-124-907-11 ELECT 10uF 20% 50V
C367 1-104-664-11 ELECT 47uF 20% 16V
C368 1-124-443-00 ELECT 100uF 20% 10V
C369 1-124-907-11 ELECT 10uF 20% 50V
C370 1-124-907-11 ELECT 10uF 20% 50V
C398 1-161-772-11 CERAMIC 0.1uF 10% 25V
< DIODE >
D351 8-719-920-76 DIODE 1S2076
D352 8-719-920-76 DIODE 1S2076
D353 8-719-920-76 DIODE 1S2076
< IC >
IC301 8-759-000-48 IC MC14052BCP
IC302 8-759-505-55 IC NJM4558L
IC351 8-759-497-89 IC TA-2041F
< JACK >
JK301 1-784-362-11 JACK, PIN 4P (MD IN/OUT)
< CONNECTOR >
M301 1-573-834-11 CONNECTOR, BOARD TO BOARD 20P
< TRANSISTOR >
Q301 8-729-231-55 TRANSISTOR 2SC2878-AB
Q302 8-729-231-55 TRANSISTOR 2SC2878-AB
Q303 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R302 1-249-417-11 CARBON 1K 5% 1/4W F
R303 1-249-417-11 CARBON 1K 5% 1/4W F
R304 1-249-417-11 CARBON 1K 5% 1/4W F
R305 1-249-417-11 CARBON 1K 5% 1/4W F
R306 1-249-417-11 CARBON 1K 5% 1/4W F
R307 1-249-425-11 CARBON 4.7K 5% 1/4W F
R308 1-249-425-11 CARBON 4.7K 5% 1/4W F
R309 1-249-421-11 CARBON 2.2K 5% 1/4W F
R310 1-249-421-11 CARBON 2.2K 5% 1/4W F
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-441-11 CARBON 100K 5% 1/4W
R313 1-249-441-11 CARBON 100K 5% 1/4W
R314 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-441-11 CARBON 100K 5% 1/4W
R316 1-249-441-11 CARBON 100K 5% 1/4W
R317 1-249-425-11 CARBON 4.7K 5% 1/4W F
R318 1-249-425-11 CARBON 4.7K 5% 1/4W F
R319 1-249-441-11 CARBON 100K 5% 1/4W
R320 1-249-441-11 CARBON 100K 5% 1/4W
R321 1-247-903-00 CARBON 1M 5% 1/4W
R322 1-247-903-00 CARBON 1M 5% 1/4W
R323 1-249-417-11 CARBON 1K 5% 1/4W F
R324 1-249-417-11 CARBON 1K 5% 1/4W F
R329 1-247-815-91 CARBON 220 5% 1/4W
R330 1-247-815-91 CARBON 220 5% 1/4W
R335 1-249-425-11 CARBON 4.7K 5% 1/4W F
R336 1-249-425-11 CARBON 4.7K 5% 1/4W F
R337 1-249-417-11 CARBON 1K 5% 1/4W F
R338 1-249-417-11 CARBON 1K 5% 1/4W F
R339 1-249-441-11 CARBON 100K 5% 1/4W
R340 1-249-441-11 CARBON 100K 5% 1/4W
R341 1-249-437-11 CARBON 47K 5% 1/4W
R342 1-249-437-11 CARBON 47K 5% 1/4W
R343 1-249-425-11 CARBON 4.7K 5% 1/4W F
R344 1-249-425-11 CARBON 4.7K 5% 1/4W F
R345 1-249-437-11 CARBON 47K 5% 1/4W
R346 1-249-437-11 CARBON 47K 5% 1/4W
R347 1-249-425-11 CARBON 4.7K 5% 1/4W F
R348 1-249-421-11 CARBON 2.2K 5% 1/4W F
R351 1-249-430-11 CARBON 12K 5% 1/4W
R352 1-249-430-11 CARBON 12K 5% 1/4W
R353 1-249-431-11 CARBON 15K 5% 1/4W
R354 1-249-431-11 CARBON 15K 5% 1/4W
R355 1-249-429-11 CARBON 10K 5% 1/4W
R356 1-249-432-11 CARBON 18K 5% 1/4W
R357 1-249-425-11 CARBON 4.7K 5% 1/4W F
R358 1-249-425-11 CARBON 4.7K 5% 1/4W F
R359 1-249-437-11 CARBON 47K 5% 1/4W
R360 1-249-437-11 CARBON 47K 5% 1/4W
R361 1-249-417-11 CARBON 1K 5% 1/4W F
R362 1-249-417-11 CARBON 1K 5% 1/4W F
R363 1-249-429-11 CARBON 10K 5% 1/4W
R364 1-249-429-11 CARBON 10K 5% 1/4W
R367 1-249-417-11 CARBON 1K 5% 1/4W F
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-421-11 CARBON 2.2K 5% 1/4W F
R370 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R551 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
**************************************************************
* A-4407-245-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C210 1-161-051-00 CERAMIC 0.01uF 10% 50V
C211 1-126-941-11 ELECT 470uF 20% 16V
C214 1-124-472-11 ELECT 470uF 20% 10V
C215 1-102-106-00 CERAMIC 100PF 10% 50V
C216 1-102-106-00 CERAMIC 100PF 10% 50V
C217 1-161-051-00 CERAMIC 0.01uF 10% 50V
C218 1-124-472-11 ELECT 470uF 20% 10V
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
FUN/SURROUND
RELAY
