– 54 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C229 1-102-074-00 CERAMIC 0.001uF 10% 50V
C235 1-126-233-11 ELECT 22uF 20% 50V
C236 1-126-233-11 ELECT 22uF 20% 50V
C241 1-102-125-00 CERAMIC 4700PF 10% 50V
C242 1-102-125-00 CERAMIC 4700PF 10% 50V
C245 1-161-772-11 CERAMIC 0.1uF 10% 25V
C246 1-126-942-61 ELECT 1000uF 20% 16V
C789 1-161-051-00 CERAMIC 0.01uF 10% 50V
C797 1-161-051-00 CERAMIC 0.01uF 10% 50V
C799 1-161-051-00 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
CNU102 1-770-067-11 CONNECTOR, FFC/FPC 19P
< DIODE >
D200 8-719-911-55 DIODE U05G
D206 8-719-911-55 DIODE U05G
D207 8-719-911-55 DIODE U05G
D208 8-719-920-76 DIODE 1S2076
D209 8-719-920-76 DIODE 1S2076
D770 8-719-911-55 DIODE U05G
D771 8-719-911-55 DIODE U05G
< COIL >
L203 1-408-096-00 INDUCTOR 470uH
< CONNECTOR >
* M704 1-564-715-11 PIN, CONNECTOR (SMALL TYPE)13P
< TRANSISTOR >
Q202 8-729-029-86 TRANSISTOR DTC124ESA
Q203 8-729-200-36 TRANSISTOR 2SA966-Y
Q213 8-729-029-86 TRANSISTOR DTC124ESA
Q214 8-729-029-86 TRANSISTOR DTC124ESA
Q215 8-729-029-86 TRANSISTOR DTC124ESA
Q770 8-729-200-36 TRANSISTOR 2SA966-Y
Q771 8-729-200-36 TRANSISTOR 2SA966-Y
Q772 8-729-029-86 TRANSISTOR DTC124ESA
Q773 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R206 1-249-430-11 CARBON 12K 5% 1/4W
R207 1-249-418-11 CARBON 1.2K 5% 1/4W F
R213 1-247-807-31 CARBON 100 5% 1/4W
R214 1-247-807-31 CARBON 100 5% 1/4W
R215 1-247-807-31 CARBON 100 5% 1/4W
R217 1-247-807-31 CARBON 100 5% 1/4W
R218 1-247-807-31 CARBON 100 5% 1/4W
R219 1-247-807-31 CARBON 100 5% 1/4W
R220 1-247-807-31 CARBON 100 5% 1/4W
R221 1-247-807-31 CARBON 100 5% 1/4W
R224 1-247-843-11 CARBON 3.3K 5% 1/4W
R231 1-249-429-11 CARBON 10K 5% 1/4W
R232 1-249-439-11 CARBON 68K 5% 1/4W
R233 1-249-429-11 CARBON 10K 5% 1/4W
R234 1-249-429-11 CARBON 10K 5% 1/4W
R235 1-249-429-11 CARBON 10K 5% 1/4W
R236 1-249-429-11 CARBON 10K 5% 1/4W
! R237 1-212-966-00 FUSIBLE 22 5% 1/2W F
R245 1-249-429-11 CARBON 10K 5% 1/4W
R265 1-249-429-11 CARBON 10K 5% 1/4W
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-429-11 CARBON 10K 5% 1/4W
R268 1-249-429-11 CARBON 10K 5% 1/4W
R271 1-249-429-11 CARBON 10K 5% 1/4W
R288 1-249-429-11 CARBON 10K 5% 1/4W
R289 1-249-429-11 CARBON 10K 5% 1/4W
R291 1-249-429-11 CARBON 10K 5% 1/4W
R295 1-249-415-11 CARBON 680 5% 1/4W F
R296 1-249-415-11 CARBON 680 5% 1/4W F
R298 1-249-435-11 CARBON 33K 5% 1/4W
R299 1-249-435-11 CARBON 33K 5% 1/4W
R771 1-249-425-11 CARBON 4.7K 5% 1/4W F
R772 1-249-434-11 CARBON 27K 5% 1/4W
R773 1-247-856-00 CARBON 11K 5% 1/4W
R774 1-249-430-11 CARBON 12K 5% 1/4W
R775 1-249-430-11 CARBON 12K 5% 1/4W
R776 1-249-418-11 CARBON 1.2K 5% 1/4W F
R777 1-249-418-11 CARBON 1.2K 5% 1/4W F
< VARIABLE RESISTOR >
VR770 1-230-497-11 RES, ADJ, CARBON 22K
< CONNECTOR >
* W103 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
W201 1-784-351-11 CONNECTOR 12P
W202 1-784-350-11 CONNECTOR 10P
W203 1-784-352-11 CONNECTOR 25P
W301 1-573-852-11 CONNECTOR, BOARD TO BOARD 20P
W703 1-766-718-11 CONNECTOR, BOARD TO BOARD 17P
W901 1-766-718-11 CONNECTOR, BOARD TO BOARD 17P
**************************************************************
* A-4407-243-A TAPE PREAMP BOARD, COMPLETE
****************************
* 4-997-378-01 PC BOARD BRACKET
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C483 1-161-051-00 CERAMIC 0.01uF 10% 50V
C484 1-161-051-00 CERAMIC 0.01uF 10% 50V
C700 1-161-051-00 CERAMIC 0.01uF 10% 50V
C703 1-102-113-00 CERAMIC 390PF 10% 50V
C704 1-102-113-00 CERAMIC 390PF 10% 50V
C705 1-104-666-11 ELECT 220uF 20% 10V
C706 1-104-666-11 ELECT 220uF 20% 10V
C707 1-102-106-00 CERAMIC 100PF 10% 50V
C708 1-102-106-00 CERAMIC 100PF 10% 50V
C709 1-137-372-11 FILM 0.022uF 5% 50V
C710 1-137-372-11 FILM 0.022uF 5% 50V
C711 1-124-907-11 ELECT 10uF 20% 50V
C712 1-124-907-11 ELECT 10uF 20% 50V
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
TAPE PREAMP
RELAY
To Next Page
