Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EH25/EH26
44
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-845-11 METAL CHIP 100K 5% 1/10W
R120 1-216-864-11 SHORT CHIP 0
R125 1-216-864-11 SHORT CHIP 0
R126 1-216-864-11 SHORT CHIP 0
R127 1-216-864-11 SHORT CHIP 0
R128 1-216-853-11 METAL CHIP 470K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-857-11 METAL CHIP 1M 5% 1/10W
R135 1-216-853-11 METAL CHIP 470K 5% 1/10W
R136 1-216-837-11 METAL CHIP 22K 5% 1/10W
R139 1-216-841-11 METAL CHIP 47K 5% 1/10W
R140 1-216-864-11 SHORT CHIP 0
R142 1-216-837-11 METAL CHIP 22K 5% 1/10W
R143 1-216-841-11 METAL CHIP 47K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R145 1-216-864-11 SHORT CHIP 0
R146 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
R149 1-216-864-11 SHORT CHIP 0
R150 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-857-11 METAL CHIP 1M 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-91 SHORT CHIP 0
R202 1-216-295-91 SHORT CHIP 0
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-809-11 METAL CHIP 100 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R304 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
CD
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1544-898-A MAIN BOARD, COMPLETE (EH25: AEP, UK/EH26)
A-1544-906-A MAIN BOARD, COMPLETE (EH25: KR)
A-1547-611-A MAIN BOARD, COMPLETE (EH25: RU)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< BAND PASS FILTER >
BPF801 1-236-711-21 FILTER, BAND PASS
< CAPACITOR/JUMPER RESISTOR >
C101 1-128-549-11 ELECT 3300uF 20% 35V
C102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C105 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EH25: AEP, RU, UK/EH26)
C105 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
(EH25: KR)
C109 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-126-953-11 ELECT 2200uF 20% 35V
C114 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C118 1-126-933-11 ELECT 100uF 20% 16V
C121 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C122 1-126-949-11 ELECT 220uF 20% 35V
C141 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C142 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C155 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C156 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C181 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C182 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C183 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C184 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C194 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C196 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C301 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-126-963-11 ELECT 4.7uF 20% 50V
C304 1-126-933-11 ELECT 100uF 20% 16V
C305 1-126-960-11 ELECT 1uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-767-11 ELECT 1000uF 20% 16V
C308 1-126-767-11 ELECT 1000uF 20% 16V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C312 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C315 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C371 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C381 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C382 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C401 1-126-956-91 ELECT 0.1uF 20% 50V
C402 1-126-933-11 ELECT 100uF 20% 16V
C403 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C404 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C405 1-126-956-91 ELECT 0.1uF 20% 50V
MAIN
