Sony HCD-EH25 - Page 49

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EH25/EH26
4949
C719 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C721 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C722 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C723 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C724 1-113-905-11 CERAMIC 220PF 10% 250V
C725 1-124-584-00 ELECT 100uF 20% 6.3V
C726 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C727 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C728 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C729 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C732 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C733 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C738 1-115-156-11 CERAMIC CHIP 1uF 10V
C739 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C740 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C741 1-115-156-11 CERAMIC CHIP 1uF 10V
C742 1-115-156-11 CERAMIC CHIP 1uF 10V
C743 1-115-156-11 CERAMIC CHIP 1uF 10V
C744 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C745 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C748 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C750 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C751 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C753 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CNP701 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CNP703 1-784-727-11 CONNECTOR, FFC 5P (EH25: RU, KR)
CNP703 1-568-850-11 CONNECTOR, FFC 7P (EH25: AEP, UK/EH26)
CNP706 1-784-780-11 CONNECTOR, FFC 19P
CNP707 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D701 6-501-163-01 DIODE UDZW-TE17-3.6B
D702 6-500-334-01 DIODE MC2836-T112-1
D703 6-500-335-01 DIODE MC2838-T112-1
D704 6-501-582-01 DIODE 1N4002-B5
D705 6-501-582-01 DIODE 1N4002-B5
< IC >
IC701 IC MB90F830PF-GE1 (for SERVICE)
IC703 6-600-349-31 IC NJL24H400A
IC706 6-711-821-01 IC
TK11135CSCL-G
IC707 6-706-964-01 IC TK70533SCL-G
IC709 6-712-923-01 IC PST3542UL
< JUMPER RESISTOR >
JR702 1-216-864-11 SHORT CHIP
0
JR705 1-216-864-11 SHORT CHIP 0
JR706 1-216-864-11 SHORT CHIP 0
JR707 1-216-864-11 SHORT CHIP 0
JR709 1-216-864-11 SHORT CHIP 0
JR710 1-216-864-11 SHORT CHIP 0
JR713 1-216-864-11 SHORT CHIP 0
JR714 1-216-864-11 SHORT CHIP 0
JR715 1-216-864-11 SHORT CHIP 0
JR719 1-216-864-11 SHORT CHIP 0
JR722 1-216-864-11 SHORT CHIP 0
JR723 1-216-864-11 SHORT CHIP 0
JR724 1-216-864-11 SHORT CHIP 0
JR725 1-216-864-11 SHORT CHIP 0
JR726 1-216-864-11 SHORT CHIP 0
JR743 1-216-864-11 SHORT CHIP 0
JR747 1-216-864-11 SHORT CHIP 0
JR748 1-216-864-11 SHORT CHIP 0
JR749 1-216-864-11 SHORT CHIP 0
JR750 1-216-864-11 SHORT CHIP 0
JR751 1-216-864-11 SHORT CHIP 0
JR752 1-216-864-11 SHORT CHIP 0
JR754 1-216-864-11 SHORT CHIP 0
JR760 1-216-864-11 SHORT CHIP 0
JR762 1-216-864-11 SHORT CHIP 0
JR763 1-216-864-11 SHORT CHIP 0
JR775 1-216-864-11 SHORT CHIP 0
JR788 1-216-864-11 SHORT CHIP 0
JR789 1-216-864-11 SHORT CHIP 0
L701 1-216-864-11 SHORT CHIP 0
L702 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD702 1-802-381-11 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED701 6-502-498-01 LED SELU2B10A-SLF62FGH
(LCD BACK LIGHT)
LED702 6-501-452-01 LED 1L4345V22DOTDT02 (STANDBY)
< TRANSISTOR >
Q701 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q702 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q703 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q704 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q705 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q706 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q707 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q708 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q709 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q710 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q711 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q712 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q713 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q714 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
< RESISTOR >
R701 1-216-817-11 METAL CHIP 470 5% 1/10W
R702 1-216-821-11 METAL CHIP 1K 5% 1/10W
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-821-11 METAL CHIP 1K 5% 1/10W
R705 1-216-821-11 METAL CHIP 1K 5% 1/10W
R706 1-216-821-11 METAL CHIP 1K 5% 1/10W
R707 1-216-821-11 METAL CHIP 1K 5% 1/10W
R708 1-216-821-11 METAL CHIP 1K 5% 1/10W
R709 1-216-821-11 METAL CHIP 1K 5% 1/10W
R710 1-216-821-11 METAL CHIP 1K 5% 1/10W
R711 1-216-821-11 METAL CHIP 1K 5% 1/10W
R712 1-216-864-11 SHORT CHIP 0
R713 1-216-833-11 METAL CHIP 10K 5% 1/10W
R714 1-216-833-11 METAL CHIP 10K 5% 1/10W
R715 1-216-809-11 METAL CHIP 100 5% 1/10W
PANEL
