40
HCD-EP515
Ref. No. Part No. Description Remarks
* CN901 1-564-509-11 PLUG, CONNECTOR 6P
* CN902 1-691-756-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-063-79 DIODE 1N4002B
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-902-17 DIODE 1N5401
D917 8-719-902-17 DIODE 1N5401
D918 8-719-902-17 DIODE 1N5401
D919 8-719-902-17 DIODE 1N5401
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
< LINE FILTER >
LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
0R911 1-219-237-51 CARBON 3.3M 5% 1/2W
(US, CND)
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-443-041-11 TRANSFORMER, POWER (KR)
0T901 1-439-781-11 TRANSFORMER, POWER (US, CND)
0T901 1-439-779-11 TRANSFORMER, POWER (AEP, UK)
************************************************************
1-688-191-11 REGULATOR BOARD
****************
< IC >
IC305 8-759-347-18 IC KIA7809PI
************************************************************
MAIN POWER REGULATOR
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.2 2003. 07
MISCELLANEOUS
**************
0 8 1-696-169-12 CORD, POWER (KR)
0 8 1-696-169-12 CORD, POWER
0 8 1-696-169-12 CORD, POWER (AEP, UK)
11 1-693-619-11 TUNER (FM/AM) (AEP,UK)
11 1-693-622-11 TUNER (KR)
11 1-693-624-11 TUNER (FM/AM) (US,CND)
65 1-796-351-51 MECHANISM, SINGLE CASSETTE
106 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
0 602 8-820-221-01 OPTICAL PICK-UP KSM-213EDP
S800 1-692-960-11 SWITCH, PUSH (1 KEY) (OPEN)
0 T902 1-439-769-11 TRANSFORMER, POWER (KR)
0 T902 1-439-778-11 TRANSFORMER, POWER (AEP, UK)
0 T902 1-439-780-11 TRANSFORMER, POWER (US, CND)
