8
HCD-EP515
3-2. CD Cabinet Section, Front Panel Section
3-3. CD Mechanism Deck (KSM-213EDP)
8
connector
(CN301)
q;
screw
(+BVTP 3
×
10)
qa
two screws
(+BVTP 3
×
10
1
connector
(S800)
9
connector
(CN307)
qf
front panel section
5
CD cabinet section
4
claw
3
claw
qs
claw
qd
claw
2
w
ire (flat type)
21p (CN101)
6
w
ire (flat type)
20p (CN303)
7
w
ire (flat type)
15p (CN302)
1
two screws
(+PWH 2.6
×
10)
4
two vibration proof rubbers (GRN)
5
CD mechanism deck
(KSM-213EDP)
3
two vibration proof rubbers (PNK
2
two screws
(+PWH 2.6
×
10)
