TA-WR2
Pin No. Pin Name I/O Description
56 VCC — Power supply terminal (+3.3V)
57 MAIN_OFF O Power off control signal output to the power control “H”: power off
58 V_CONT O Voltage control PWM signal output to the shunt regulator
59 DAMP_LATCH O Latch control signal output to the stream processor
60 DAMP_SHIFT O Shift clock signal output to the stream processor
61 DAMP_SCDT O Serial data output to the stream processor
62 SI2 I Serial data input terminal
63 INT24 O Not used
64 NC O Not used
