HCD-FX100W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R5452 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5453 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5504 1-216-815-11 METAL CHIP 330 5% 1/10W
R5505 1-216-815-11 METAL CHIP 330 5% 1/10W
R5524 1-216-815-11 METAL CHIP 330 5% 1/10W
R5525 1-216-815-11 METAL CHIP 330 5% 1/10W
R5526 1-216-815-11 METAL CHIP 330 5% 1/10W
R5527 1-216-815-11 METAL CHIP 330 5% 1/10W
R5528 1-216-815-11 METAL CHIP 330 5% 1/10W
R5529 1-216-815-11 METAL CHIP 330 5% 1/10W
R5530 1-216-815-11 METAL CHIP 330 5% 1/10W
R5531 1-216-815-11 METAL CHIP 330 5% 1/10W
R5534 1-216-815-11 METAL CHIP 330 5% 1/10W
R5535 1-216-815-11 METAL CHIP 330 5% 1/10W
R5536 1-216-815-11 METAL CHIP 330 5% 1/10W
R5537 1-216-815-11 METAL CHIP 330 5% 1/10W
R5538 1-216-815-11 METAL CHIP 330 5% 1/10W
R5539 1-216-815-11 METAL CHIP 330 5% 1/10W
R5540 1-216-815-11 METAL CHIP 330 5% 1/10W
R5541 1-216-815-11 METAL CHIP 330 5% 1/10W
R5544 1-216-864-11 SHORT CHIP 0
R5545 1-216-864-11 SHORT CHIP 0
R5546 1-216-864-11 SHORT CHIP 0
R5547 1-216-864-11 SHORT CHIP 0
R5548 1-216-864-11 SHORT CHIP 0
R5549 1-216-864-11 SHORT CHIP 0
R5550 1-216-864-11 SHORT CHIP 0
R5551 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB5501 1-234-795-21 RES, NETWORK 0X4 (2010)
RB5502 1-234-795-21 RES, NETWORK 0X4 (2010)
< VARIABLE RESISTOR >
RV501 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
RV502 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
< VIBRATOR >
X601 1-813-430-11 PIEZOELECTRIC OSCILLATOR (8MHz)
************************************************************
MIB01 POWER BOARD
******************
< CAPACITOR >
C905 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C906 1-126-969-11 ELECT 220uF 20% 50V
C907 1-128-949-31 ELECT 470uF 20% 16V
C908 1-104-658-91 ELECT 100uF 20% 10V
C909 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C910 1-104-658-91 ELECT 100uF 20% 10V
C911 1-104-658-91 ELECT 100uF 20% 10V
C912 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C913 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
< CONNECTOR >
CN9001 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN9002 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D9021 6-500-258-01 DIODE RK16
D9022 6-500-522-01 DIODE 10EDB40-TA1B2
D9023 8-719-210-21 DIODE 11EQS04
< IC >
IC901 6-700-850-01 IC SI-8050JD-TP
IC902 6-707-568-01 IC TA48033F-TE16L
< COIL >
L9021 1-456-468-11 INDUCTOR 100uH
L9022 1-414-398-11 INDUCTOR 10uH
L9023 1-414-398-11 INDUCTOR 10uH
L9024 1-414-398-11 INDUCTOR 10uH
< RESISTOR >
R902 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R903 1-211-991-11 METAL CHIP 82 0.5% 1/10W
< TERMINAL BOARD >
TK9001 1-537-770-21 TERMINAL BOARD, GROUND
TK9002 1-537-770-21 TERMINAL BOARD, GROUND
************************************************************
1-686-724-13 MODE MOTOR BOARD
******************
************************************************************
A-4731-113-A RELAY BOARD, COMPLETE
(including ST ENCODER BOARD)
*********************
< CAPACITOR >
C711 1-126-795-11 ELECT 10uF 20% 50V
C751 1-164-159-21 CERAMIC 0.1uF 50V
C752 1-164-159-21 CERAMIC 0.1uF 50V
C753 1-164-159-21 CERAMIC 0.1uF 50V
C754 1-164-159-21 CERAMIC 0.1uF 50V
C755 1-164-159-21 CERAMIC 0.1uF 50V
C756 1-164-159-21 CERAMIC 0.1uF 50V
C758 1-164-159-21 CERAMIC 0.1uF 50V
C761 1-162-306-11 CERAMIC 0.01uF 20% 16V
C762 1-164-159-21 CERAMIC 0.1uF 50V
C763 1-164-159-21 CERAMIC 0.1uF 50V
C764 1-164-159-21 CERAMIC 0.1uF 50V
C765 1-164-159-21 CERAMIC 0.1uF 50V
C766 1-164-159-21 CERAMIC 0.1uF 50V
C767 1-164-159-21 CERAMIC 0.1uF 50V
C768 1-164-159-21 CERAMIC 0.1uF 50V
C769 1-164-159-21 CERAMIC 0.1uF 50V
C771 1-162-306-11 CERAMIC 0.01uF 20% 16V
C781 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN701 1-779-564-21 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
CN702 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
MIB01 MIB01 POWER RELAYMODE MOTOR
