119
HCD-FX100W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN703 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
* CN710 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D701 8-719-921-44 DIODE MTZJ-5.1C
D711 8-719-109-92 DIODE RD6.2ESB1
D721 8-719-982-11 DIODE MTZJ-4.3B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
IC721 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R721 1-249-415-11 CARBON 680 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R731 1-247-806-11 CARBON 91 5% 1/4W
R732 1-249-417-11 CARBON 1K 5% 1/4W
R733 1-249-429-11 CARBON 10K 5% 1/4W
R734 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
1-686-726-13 ROLLER MOTOR BOARD
*******************
************************************************************
1-686-723-13 SENSOR BOARD
************
< IC >
IC751 8-749-017-45 SENSOR, PHONT RPR-220C1N
************************************************************
A-4731-113-A ST ENCODER BOARD, COMPLETE
(including RELAY BOARD)
***************************
************************************************************
1-686-725-13 STOCKER MOTOR BOARD
********************
************************************************************
1-686-727-13 SW (1) BOARD
************
< SWITCH >
S711 1-786-382-21 SWITCH, PUSH (1 KEY)
(DISC INSERT (8/12cm))
************************************************************
1-686-728-13 SW (2) BOARD
************
< SWITCH >
S713 1-786-382-21 SWITCH, PUSH (1 KEY) (DISC IN (8/12cm))
S714 1-786-382-21 SWITCH, PUSH (1 KEY) (DISC IN (8cm))
************************************************************
1-686-729-13 SW (3) BOARD
************
< SWITCH >
S715 1-786-382-21 SWITCH, PUSH (1 KEY) (DISC OUT)
************************************************************
1-686-730-13 SW (4) BOARD
************
< SWITCH >
S716 1-786-382-21 SWITCH, PUSH (1 KEY) (STOCKER IN/OUT)
S717 1-786-382-21 SWITCH, PUSH (1 KEY) (DISC POSITION)
S718 1-786-382-21 SWITCH, PUSH (1 KEY) (STOCKING)
************************************************************
A-1111-100-A TX BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-128-950-21 ELECT 1000uF 20% 16V
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-126-933-11 ELECT 100uF 20% 16V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C812 1-104-658-91 ELECT 100uF 20% 10V
C813 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C819 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C820 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C821 1-104-658-91 ELECT 100uF 20% 10V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C826 1-104-658-91 ELECT 100uF 20% 10V
C827 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C832 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
RELAY ROLLER MOTOR SENSOR ST ENCODER
STOCKER MOTOR SW(1) SW(2) SW(3) SW(4) TX
