120
HCD-FX100W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C834 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C835 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C836 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C839 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C841 1-126-961-11 ELECT 2.2uF 20% 50V
C842 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C845 1-104-658-91 ELECT 100uF 20% 10V
C846 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C847 1-126-933-11 ELECT 100uF 20% 16V
C848 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C849 1-126-933-11 ELECT 100uF 20% 16V
C850 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C860 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C861 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C863 1-128-950-21 ELECT 1000uF 20% 16V
C864 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C865 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-784-370-21 CONNECTOR, FFC/FPC 11P
CN802 1-564-505-11 PLUG, CONNECTOR 2P
CN803 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D800 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL BOARD >
EB801 1-537-770-21 TERMINAL BOARD, GROUND
EB802 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB804 1-414-234-22 INDUCTOR, FERRITE BEAD
< IC >
IC800 6-703-550-01 IC TA7809LS
IC801 6-704-261-01 IC TK11225CMCL-G
IC802 8-759-548-99 IC SN74LV08APWR
IC803 8-759-549-01 IC SN74LV125APWR
IC804 8-752-425-05 IC CXD4016R
IC805 8-759-684-21 IC AD8057ARTZ-REEL7
< COIL >
L802 1-469-525-91 INDUCTOR 10uH
L803 1-469-525-91 INDUCTOR 10uH
L804 1-469-525-91 INDUCTOR 10uH
L805 1-469-525-91 INDUCTOR 10uH
L806 1-469-525-91 INDUCTOR 10uH
L807 1-469-525-91 INDUCTOR 10uH
L808 1-469-525-91 INDUCTOR 10uH
L809 1-469-525-91 INDUCTOR 10uH
L810 1-469-525-91 INDUCTOR 10uH
L811 1-400-305-11 INDUCTOR 47uH
L812 1-456-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q801 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R803 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-809-11 METAL CHIP 100 5% 1/10W
R811 1-216-821-11 METAL CHIP 1K 5% 1/10W
R812 1-216-815-11 METAL CHIP 330 5% 1/10W
R813 1-216-813-11 METAL CHIP 220 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-815-11 METAL CHIP 330 5% 1/10W
R816 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R818 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R820 1-216-813-11 METAL CHIP 220 5% 1/10W
R821 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R822 1-216-811-11 METAL CHIP 150 5% 1/10W
R823 1-216-813-11 METAL CHIP 220 5% 1/10W
R824 1-216-817-11 METAL CHIP 470 5% 1/10W
R825 1-216-833-11 METAL CHIP 10K 5% 1/10W
R826 1-216-811-11 METAL CHIP 150 5% 1/10W
R827 1-216-811-11 METAL CHIP 150 5% 1/10W
R829 1-216-835-11 METAL CHIP 15K 5% 1/10W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-220-397-11 METAL CHIP 4.7M 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-833-11 METAL CHIP 10K 5% 1/10W
R834 1-216-833-11 METAL CHIP 10K 5% 1/10W
R835 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R836 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R837 1-216-803-11 METAL CHIP 33 5% 1/10W
R838 1-216-821-11 METAL CHIP 1K 5% 1/10W
R839 1-216-809-11 METAL CHIP 100 5% 1/10W
R840 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-809-11 METAL CHIP 100 5% 1/10W
R843 1-216-809-11 METAL CHIP 100 5% 1/10W
R844 1-216-809-11 METAL CHIP 100 5% 1/10W
< VARIABLE RESISTOR >
RV801 1-223-582-11 RES, ADJ, CARBON 470
< VIBRATOR >
X801 1-795-044-21 VIBRATOR, CRYSTAL (24.576MHz)
************************************************************
TX
