— 63 —
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
SECTION 7
ELECTRICAL PARTS LIST
CD DECODER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-4398-909-A CD DECODER BOARD, COMPLETE
**************************
< CAPACITOR >
C02 1-126-963-11 ELECT 4.7uF 20% 50V
C03 1-126-933-11 ELECT 100uF 20% 10V
C04 1-162-306-11 CERAMIC 0.01uF 20% 16V
C05 1-136-159-00 FILM 0.033uF 5% 50V
C06 1-162-306-11 CERAMIC 0.01uF 20% 16V
C07 1-136-159-00 FILM 0.033uF 5% 50V
C07A 1-162-199-31 CERAMIC 10PF 5% 50V
C08 1-161-494-00 CERAMIC 0.022uF 25V
C09 1-126-959-11 ELECT 0.47uF 20% 50V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-933-11 ELECT 100uF 20% 10V
C11A 1-164-159-11 CERAMIC 0.1uF 50V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-164-159-11 CERAMIC 0.1uF 50V
C14 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-136-159-00 FILM 0.033uF 5% 50V
C17 1-136-165-00 FILM 0.1uF 5% 50V
C18 1-164-159-11 CERAMIC 0.1uF 50V
C19 1-126-963-11 ELECT 4.7uF 20% 50V
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-136-157-00 FILM 0.022uF 5% 50V
C22 1-126-933-11 ELECT 100uF 20% 10V
C23 1-164-159-11 CERAMIC 0.1uF 50V
C24 1-126-965-11 ELECT 22uF 20% 50V
C25 1-126-960-11 ELECT 1uF 20% 50V
C26 1-161-494-00 CERAMIC 0.022uF 30% 25V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C28 1-164-159-11 CERAMIC 0.1uF 50V
C29 1-126-935-11 ELECT 470uF 20% 16V
C30 1-126-933-11 ELECT 100uF 20% 10V
C31 1-162-600-11 CERAMIC 0.047uF 10% 16V
C32 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C33 1-162-306-11 CERAMIC 0.01uF 20% 16V
C34 1-162-286-31 CERAMIC 220PF 10% 50V
C35 1-162-306-11 CERAMIC 0.01uF 20% 16V
C36 1-126-963-11 ELECT 4.7uF 20% 50V
C37 1-164-159-11 CERAMIC 0.1uF 50V
C38 1-102-958-00 CERAMIC 20PF 5% 50V
C39 1-102-958-00 CERAMIC 20PF 5% 50V
C42 1-126-012-11 ELECT 470uF 20% 16V
C43 1-126-933-11 ELECT 100uF 20% 10V
C45 1-126-923-11 ELECT 220uF 20% 10V
C46 1-126-933-11 ELECT 100uF 20% 10V
C51 1-162-288-31 CERAMIC 330PF 10% 50V
C51A 1-126-959-11 ELECT 0.47uF 20% 50V
C52 1-162-288-31 CERAMIC 330PF 10% 50V
C53 1-162-284-31 CERAMIC 150PF 10% 50V
C54 1-162-284-31 CERAMIC 150PF 10% 50V
C55 1-162-284-31 CERAMIC 150PF 10% 50V
C56 1-162-284-31 CERAMIC 150PF 10% 50V
C57 1-126-961-11 ELECT 2.2uF 20% 50V
C58 1-126-961-11 ELECT 2.2uF 20% 50V
C59 1-162-294-31 CERAMIC 0.001uF 10% 50V
C60 1-162-294-31 CERAMIC 0.001uF 10% 50V
C80 1-164-159-11 CERAMIC 0.1uF 50V
C81 1-164-159-11 CERAMIC 0.1uF 50V
C82 1-164-159-11 CERAMIC 0.1uF 50V
C83 1-164-159-11 CERAMIC 0.1uF 50V
C84 1-162-282-31 CERAMIC 100PF 10% 50V
C85 1-162-292-31 CERAMIC 680PF 10% 50V
C86 1-162-282-31 CERAMIC 100PF 10% 50V
C86A 1-161-494-00 CERAMIC 0.022uF 25V
C87 1-162-282-31 CERAMIC 100PF 10% 50V
C88 1-162-282-31 CERAMIC 100PF 10% 50V
C89 1-161-494-00 CERAMIC 0.022uF 25V
C90 1-161-494-00 CERAMIC 0.022uF 25V
C93 1-126-925-11 ELECT 470uF 20% 10V
C94 1-126-933-11 ELECT 100uF 20% 10V
C98 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN01 1-580-475-11 SOCKET, CONNECTOR 16P
CN05 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN06 1-695-366-21 PIN, CONNECTOR (PC BOARD) 5P
CN09 1-695-382-11 PIN, CONNECTOR (PC BOARD) 21P
< DIODE >
D01 8-719-987-63 DIODE 1N4148M
D03 8-719-109-89 DIODE RD5.6ESB2
D09 8-719-109-93 DIODE RD6.2ESB2
D20 8-719-987-63 DIODE 1N4148M
D21 8-719-987-63 DIODE 1N4148M
D22 8-719-987-63 DIODE 1N4148M
D23 8-719-987-63 DIODE 1N4148M
D24 8-719-987-63 DIODE 1N4148M
D25 8-719-987-63 DIODE 1N4148M
D26 8-719-987-63 DIODE 1N4148M
D27 8-719-987-63 DIODE 1N4148M
D35 8-719-982-11 DIODE MTZJ-4.3B
D36 8-719-031-85 DIODE 1N4002L
To Next Page
