— 65 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R91 1-249-839-11 CARBON 2.2K 5% 1/4W
R92 1-249-839-11 CARBON 2.2K 5% 1/4W
R93 1-249-420-11 CARBON 1.8K 5% 1/4W F
R93A 1-249-420-11 CARBON 1.8K 5% 1/4W F
R94 1-249-420-11 CARBON 1.8K 5% 1/4W F
R94A 1-249-420-11 CARBON 1.8K 5% 1/4W F
R99 1-247-704-11 CARBON 220 5% 1/4W F
< VARIABLE RESISTOR >
VR01 1-228-996-00 RES, ADJ, METAL 47K
VR02 1-228-998-00 RES, ADJ, METAL 220K
< VIBRATOR >
XTL01 1-760-123-11 VIBRATOR, CRYSTAL (33.8688MHz)
**************************************************************
* 1-666-626-11 DISC BOARD
**********
< SWITCH >
S623 1-572-481-11 SWITCH, KEY BOARD (1 KEY)(6 OPEN/CLOSE)
S624 1-572-481-11 SWITCH, KEY BOARD (1 KEY)(DISC 1)
S625 1-572-481-11 SWITCH, KEY BOARD (1 KEY)(DISC 2)
S626 1-572-481-11 SWITCH, KEY BOARD (1 KEY)(DISC 3)
S627 1-572-481-11 SWITCH, KEY BOARD (1 KEY)(DISC SKIP)
**************************************************************
* 1-666-624-11 H/P BOARD
*********
< JACK >
JK303 1-779-715-11 JACK (LARGE TYPE)(PHONES)
< RESISTOR >
R373 1-247-695-11 CARBON 39 5% 1/4W F
R374 1-247-695-11 CARBON 39 5% 1/4W F
**************************************************************
* A-4403-093-A MAIN BOARD, COMPLETE
*********************
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C101 1-162-294-31 CERAMIC 0.001uF 10% 50V
C102 1-162-294-31 CERAMIC 0.001uF 10% 50V
C103 1-162-193-31 CERAMIC 3.3PF 10% 50V
C104 1-161-494-00 CERAMIC 0.022uF 25V
C105 1-162-206-31 CERAMIC 20PF 5% 50V
C106 1-161-494-00 CERAMIC 0.022uF 25V
C107 1-161-494-00 CERAMIC 0.022uF 25V
C108 1-104-665-11 ELECT 100uF 20% 16V
C109 1-162-191-31 CERAMIC 2.2PF 10% 50V
C110 1-162-191-31 CERAMIC 2.2PF 10% 50V
C111 1-162-217-31 CERAMIC 56PF 5% 50V
C112 1-162-282-31 CERAMIC 100PF 10% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-162-294-31 CERAMIC 0.001uF 10% 50V
C116 1-130-014-00 FILM 470PF 5% 50V
C117 1-162-206-31 CERAMIC 20PF 5% 50V
C118 1-104-665-11 ELECT 100uF 20% 16V
C119 1-161-494-00 CERAMIC 0.022uF 25V
C120 1-161-494-00 CERAMIC 0.022uF 25V
C121 1-162-203-31 CERAMIC 15PF 5% 50V
C122 1-126-961-11 ELECT 2.2uF 20% 50V
C123 1-124-903-11 ELECT 1uF 20% 50V
C124 1-162-206-31 CERAMIC 20PF 5% 50V
C125 1-124-903-11 ELECT 1uF 20% 50V
C126 1-110-671-31 CERAMIC 47000PF 50V
C127 1-124-907-11 ELECT 10uF 20% 50V
C128 1-161-494-00 CERAMIC 0.022uF 25V
C129 1-109-889-11 ELECT 1uF 20% 50V
C130 1-161-054-00 CERAMIC 0.018uF 10% 25V
C131 1-161-054-00 CERAMIC 0.018uF 10% 25V
C132 1-161-047-00 CERAMIC 0.0047uF 10% 50V
C133 1-161-047-00 CERAMIC 0.0047uF 10% 50V
C134 1-162-294-31 CERAMIC 0.001uF 10% 50V
C135 1-126-962-11 ELECT 3.3uF 20% 50V
C137 1-126-959-11 ELECT 0.47uF 20% 50V
C138 1-161-494-00 CERAMIC 0.022uF 25V
C139 1-161-494-00 CERAMIC 0.022uF 25V
C140 1-104-665-11 ELECT 100uF 20% 16V
C141 1-161-494-00 CERAMIC 0.022uF 25V
C142 1-104-665-11 ELECT 100uF 20% 16V
C143 1-126-959-11 ELECT 0.47uF 20% 50V
C144 1-161-494-00 CERAMIC 0.022uF 25V
C145 1-162-217-31 CERAMIC 56PF 5% 50V
C146 1-162-294-31 CERAMIC 0.001uF 10% 50V
C148 1-161-494-00 CERAMIC 0.022uF 25V
C149 1-162-294-31 CERAMIC 0.001uF 10% 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-233-11 ELECT 22uF 20% 50V
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-162-282-31 CERAMIC 100PF 10% 50V
C155 1-162-282-31 CERAMIC 100PF 10% 50V
C156 1-102-516-11 CERAMIC 27PF 5% 50V
C157 1-102-516-11 CERAMIC 27PF 5% 50V
C158 1-104-664-11 ELECT 47uF 20% 16V
C159 1-161-379-00 CERAMIC 0.01uF 20% 25V
C160 1-126-963-11 ELECT 4.7uF 20% 50V
C161 1-126-963-11 ELECT 4.7uF 20% 50V
C162 1-161-494-00 CERAMIC 0.022uF 25V
C201 1-162-286-31 CERAMIC 220PF 10% 50V
C202 1-162-286-31 CERAMIC 220PF 10% 50V
C203 1-162-294-31 CERAMIC 0.001uF 10% 50V
C204 1-162-294-31 CERAMIC 0.001uF 10% 50V
C205 1-162-286-31 CERAMIC 220PF 10% 50V
C206 1-162-286-31 CERAMIC 220PF 10% 50V
C207 1-104-664-11 ELECT 47uF 20% 16V
C208 1-104-664-11 ELECT 47uF 20% 16V
C209 1-161-052-00 CERAMIC 0.012uF 10% 25V
C210 1-161-052-00 CERAMIC 0.012uF 10% 25V
MAINDISC H/P
CD DECODER
