Sony HCD-GN600 - 7-1. CIRCUIT BOARD LOCATION

26
HCD-GN600
7-1. CIRCUIT BOARD LOCATION
TUNER PACK
SUB TRANS board
POWER AMP boar
d
TRANS board
DISPLAY board
VOLUME board
GAME IN board
MOTOR (LD) board
SW board
SENSOR board
CD board
MOTOR (TB) board
DRIVER board
MAIN board
CD SWITCH board
